Settings Relating to
Signal Inputs
Configures settings for primary inputs 1 to 160.
Number of inputs
The number of inputs per connector board (4K format/HD
format) is given below.
a) 8 when the signal format is 1080P/59.94 or 1080P/50.
The maximum number of inputs is 160 for HD format and
40 for 4K format (with combination of ten XKS-S8110 or
XKS-T8110 boards installed).
4K format input settings
Four input connectors are assigned as a single group to a
4K signal.
A single group comprises four inputs in numeric order, and
settings are applied to the first number in each group.
1080P/59.94 and 1080P/50 format input settings
The number of inputs on an NMI connector board (XKS-
T8110) is half the number of connectors on an SDI
connector board (XKS-S8110).
On an NMI board, only odd-numbered inputs can be
configured.
Setting Through Mode
1
In the Engineering Setup >Switcher >Input menu
(7332), select the target input signal to set.
2
To enable through mode, press [Through Mode],
turning it on.
Setting the Illegal Color Limiter
This sets the illegal color limiter for the signal generated
by the switcher internal matte generator.
To enable, in the Engineering Setup >Switcher >Input
menu (7332), press [Matte Illeg Col Limit], turning it on.
Setting Format Converter Inputs
You can set internal format converter inputs if the XKS-
8460 Format Converter Board is installed.
• Supported only when the switcher signal format is 4K.
• Only input signals with 1080i format can be converted.
Assigning a primary input to an FC
channel
You can assign primary input used by the format converter
to FC channels (FC1 to FC16).
• An FC channel configured for format converter output
use cannot be selected.
For details, see “Setting the Format Converter
Configuration” (page 408).
• The configurable FC channels are FC1, FC5, FC9, and
FC13 only.
1
In the Engineering Setup >Switcher >Input menu
(7332), press [Internal FC].
The Internal FC menu (7332.5) appears.
2
Press [FC Input Select].
The FC Input Select menu (7332.3) appears.
The status area shows the FC channel list on the left
and the primary input list on the right.
3
In the list on the left, select the target FC channel to set.
4
In the list on the right, select the primary input.
5
Press [Set].
To set the source name of the converted input
signal
1
Select the target FC channel to set, and press [FC
Name].
2
Enter a name of up to 16 characters in the keyboard
window, and press [Enter].
Input connector board Number of inputs
Name Interface 4K HD
XKS-S8110 SDI
input connector
board
SDI 4 16
XKS-T8110 IP
input connector
board
NMI 4 16
a)
Input connector number Setting number
1, 2, 3, 4 1
5, 6, 7, 8 5
9, 10, 11, 12 9
13, 14, 15, 16 13
(and so on) (and so on)
Notes
Notes
