408
Cropping a 4:3 Mode Image in HD
Format
In HD format, this allows you to crop an image having a
screen aspect ratio of 16:9 to an aspect ratio of 4:3 for
output (4:3 crop).
When a screen aspect ratio of 16:9 is set in the Engineering
Setup >System >Format menu (7313), 4:3 cropping is
disabled.
1
In the Engineering Setup >Switcher >Output menu
(7333), press [4:3 Crop].
The 4:3 Crop menu (7333.5) appears.
2
Select the target output to set.
3
Press [4:3 Crop], turning it on.
Setting the Format Converter
Configuration
Up to 16 channels of internal format converter are
supported by installing an XKS-8460 Format Converter
Board.
You can set four groups of format converters, each
comprising four channels (FC1 to FC4, FC5 to FC8, FC9
to FC12, FC13 to FC16), for inputs (input signal
conversion) or outputs (output signal conversion).
Format converters can only be used when the switcher
signal format is 4K.
For details about format converter input/output settings,
see “Setting Format Converter Inputs” (page 404) and
“Setting Format Converter Outputs” (page 408).
1
In the Engineering Setup >Switcher >Output menu
(7333), press [Internal FC].
The Internal FC menu (7333.15) appears.
2
Press [FC Config].
The FC Config menu (7333.16) appears.
3
In the <FC Config> group, select the format converter
configuration.
4 in: Set four groups for inputs.
2 in / 2 out: Set two groups (FC1 to FC4, FC5 to FC8)
for inputs, and two groups (FC9 to FC12, FC13 to
FC16) for outputs.
4 out: Set four groups for outputs.
To clear the setting
Press [Clear].
4
Press [Execute].
Setting Format Converter Outputs
You can set internal format converter outputs if the XKS-
8460 Format Converter Board is installed.
You can convert signals assigned to format converter
outputs 1, 5, 9, and 13 using the format converter.
Format converter outputs 1, 5, 9, and 13 correspond to
format converter channels with the same number (FC1,
FC5, FC9, and FC13).
• Supported only when the switcher signal format is 4K.
• An FC channel configured for format converter input use
cannot be selected.
For details, see “Setting the Format Converter
Configuration” (page 408).
• Conversion using a format converter cannot be used on
outputs where the active area is set to [4096×2160].
Assigning a signal to a format converter
output
You can assign a signal to convert by the format converter
to the format converter output corresponding to the FC
channel.
1
In the Engineering Setup >Switcher >Output menu
(7333), press [Internal FC].
The Internal FC menu (7333.15) appears.
2
Press [FC Output Select].
The FC Output Select menu (7333.14) appears.
The status area shows a list of FC channel numbers and
source names of the signals assigned to the
corresponding format converter output on the left.
3
In the <FC Output Assign> group, set the signals to
display in the list on the right.
For details, refer to step 2 in “Assigning Output
Signals” (page 406).
4
Select the FC channel number and signal to assign.
Note
Note
Notes
