Coupling external boxes
By coupling a number of external boxes, the number of
inputs can be increased.
This section describes the coupling of external boxes 1 and
2 as an example.
1
In the <Device> group of the Engineering Setup
>Router/Tally >Router >External Box Assign menu
(7361.1), select [External Box1].
2
In the <Matrix Size> group, select [8×1].
3
Set the following parameters.
4
In the <Device> group, select [External Box2].
5
In the <Matrix Size> group, select [32×1].
6
Set the parameters.
Set the [Destination] and [Level] parameters to the
same values set in step 3.
This automatically couples external boxes 1 and 2,
which can be used an external box with 40 (8+32)
inputs.
Setting the group number of an S-Bus
description name
Set the group number of an S-Bus description name.
1
In the
<Alias Name Gp> grou
p of the Eng
ineering
Setup >Router/Tally >Router menu (7361), press [Gp
No].
2
Set the following parameter.
a) When a value of 1 to 7 is selected, a “0” description name appears if
a name is not set.
If the “0” description name is also not registered, “Type” and “No”
appears.
3
In the
<Alias Name Gp> grou
p, press [Set].
Send the description name selected here from the router.
Tally Group Settings
Using the S-Bus protocol, tally control is possible for
groups 1 to 8.
In this system, you select groups to use from among groups
1 to 4 or among groups 5 to 8. You can also set whether or
not to transfer the tally information over the S-Bus.
1
Open the Engineering Setup >Router/Tally >Group
Tally menu (7362).
2
To use both groups 1 to 4 and groups 5 to 8, press [All
Group Enable], turning it on.
3
In the <Tally Group> group, select groups from among
groups 1 to 4 or among groups 5 to 8.
To select more than one group, select groups with
consecutive numbers from among the groups.
4
To enable tally information on the S-Bus, press [SBus
Tally Enable], turning it on.
