Serial Tally Settings
There are two serial tally ports in each system interface
unit.
Configure settings, including tally type and source
address, for each serial tally port.
The system interface units that support serial tally output
are SIU1 and SIU2.
You can set SIU1 from the menu panel with unit ID of “1,”
and SIU2 from the menu panel with unit ID of “2.”
Configuring/Modifying Serial Tally
1
In the <Serial Tally Port> of the Engineering Setup
>Router/Tally >Serial Tally menu (7367), select the
target port to set.
2
In the <Tally Group> group, select the tally group.
3
In the <Tally Type> group, select the tally types.
Up to four tally types can be selected.
The selectable tally types depend on the setting
selected in step 2.
4
In the <Tally Data Size> group, select the data size.
128 Bit: 128 bits
256 Bit: 256 bits
Configuring the Serial Tally Source
Address
1
In the Engineering Setup >Router/Tally >Serial Tally
menu (7367), press [Source Assign].
The Source Assign menu (7367.1) appears.
2
In the <Serial Tally Port> group, select the target port
to set.
3
Select the bit number of the port.
4
Select the source address.
5
Press [Source Address Set].
Clearing Source Address Settings
To clear a source address setting for each bit
In the Engineering Setup >Router/Tally >Serial Tally
>Source Assign menu (7367.1), select the serial tally port
and bit number, then press [Clear].
The source address setting for the selected bit is cleared.
To clear all source address settings
In the Engineering Setup >Router/Tally >Serial Tally
>Source Assign menu (7367.1), select the serial tally port
and press [All Clear]. Check the message, then press [Yes].
All source address settings for the selected serial tally port
are cleared.
To return all source address settings to the
default
In the Engineering Setup >Router/Tally >Serial Tally
>Source Assign menu (7367.1), select the serial tally port
and press [Default Recall]. Check the message, then press
[Yes].
All source address settings for the selected serial tally port
are returned to the defaults.
