Saving and Recalling Setup Data
Updating the switcher or control panel setup data saves the
updated setup data in RAM in each device.
• In Resume mode (see page 366), even if devices are
reset or powered off, the data is preserved in RAM, and
recalled when the power is turned back on.
• In Custom mode (see page 366), the user-defined
settings (user setup data) saved in non-volatile memory
is recalled when a reset occurs or power is turned back
on.
The setup data in RAM can also be saved to the local drive
or removable drive on the menu panel.
Selecting the Startup State
1
In the Engineering Setup >System >Start Up menu
(7314), select the target device to set.
2
In the <Start Up Mode> group, select the mode.
Resume: Resume mode (see page 366)
Custom: Custom mode (see page 366)
[Resume] is enabled only when a switcher or control
panel is selected.
3
When [Custom] is selected, in the <Setup> group or
<Initial Status> group, select one of the following.
User: Set user-defined settings for the Setup or Initial
Status settings.
Factory: Set factory default settings for the Setup or
Initial Status settings.
4
Press [Execute].
5
Check the message, then press [Yes].
Saving User-Defined Settings
1
Open the Engineering Setup >System >Start Up menu
(7314).
2
Select the target device to set, and perform the
following operation.
• To save Setup settings, press [Setup Define].
• To save Initial Status settings, press [Init Status
Define].
3
Check the message, then press [Yes].
For details about settings that are saved, see “Data Saved
by [Setup Define] and [Initial Status Define]” (page 474).
Note
Load Save
Current setup data
(If in Resume mode, settings data is saved.)
Save
In Custom mode,
power on or reset
Initialize
Factory default setup
data
Setup
menu:
[Setup
Define]
Setup
menu:
[All Clear]
File menu
[Load]
File menu
[Save]
Local drive / removable drive
Non-volatile memory
RAM
User setup data
Non-volatile memory
User setup data
