111
When selecting [Multi] and replicating the pattern
a) See page 138.
When selecting [Aspect] and adjusting the pattern
aspect ratio
a) See page 137.
When selecting [Angle] in the <Rotation> group
and slanting the pattern
a) See page 137.
When selecting [Speed] in the <Rotation> group
and rotating the pattern at a constant speed
a) See page 137.
6
To interchange color 1 and color 2, press the [Color
Invert] button, turning it on.
Applying the zabton effect
1
In the M/E-1 >Key1 >Edge menu (1112), press
[Zabton], turning it on.
2
Set the following parameters.
If [Mask Pattern] is selected in step 4 and [Box] is
selected for the main mask, you cannot change the
[Size] parameter. Set it in the M/E-1 >Key1 >Main
Mask menu (1113).
3
Press [Zabton Adjust].
The Zabton Adjust menu (1112.3) appears.
4
In the <Zabton Pattern> group, select the pattern.
Key Wipe: Uses a key wipe.
Pressing [Pattern Select] opens the M/E-1 >Key1
>Transition/Video Process >Wipe Adjust
>Pattern Select menu (1117.2), allowing you to
select a pattern. Pressing [Pattern Adjust] opens
the M/E-1 >Key1 >Transition/Video Process
>Wipe Adjust menu (1117.1), allowing you to
adjust the pattern.
Key Edge Pattern: Uses a color mixing pattern for
key edge.
Pressing [Pattern Select] opens the M/E-1 >Key1
>Edge >Matte Adjust >Mix Ptn Select menu
(1112.2), allowing you to select a pattern. Pressing
[Pattern Adjust] opens the M/E-1 >Key1 >Edge
>Matte Adjust menu (1112.1), allowing you to
adjust the pattern.
Mask Pattern: Use the main mask source.
Pressing [Pattern Select] opens the M/E-1 >Key1
>Main Mask menu (1113), allowing you to select
[Box] or [Pattern] in the <Mask Source> group.
5
Press [Zabton Color] and adjust the color.
Mask
There are two masks, which can be used to mask off
unneeded parts of a key or background, or to remove
defects, and these are known as the main mask and sub
mask.
You can either use the main mask and sub mask
independently, or at the same time.
Using the main mask
1
Open the M/E-1 >Key1 >Main Mask menu (1113).
2
In the <Mask Type> group, select the mask type.
Key Mask: Masks a part of a key.
Bkgd Mask: Masks a part of a background.
3
In the <Mask Source> group, select the mask source.
Box: Signal from dedicated box generator
Pattern: Signal from dedicated pattern generator
No. Parameter Adjustment
1 H Multi Number of repetitions of pattern
horizontally
2 V Multi Number of repetitions of pattern
vertically
3 Invert Type Replication layout
a)
No. Parameter Adjustment
1 Aspect Aspect ratio
a)
No. Parameter Adjustment
1 Angle Rotation angle of pattern
a)
No. Parameter Adjustment
1 Speed Rotation speed of pattern
a)
No. Parameter Adjustment
1 Size Pattern size
2 Soft Degree of softness of pattern edge
3DensityDensity
Note
No. Parameter Adjustment
1 Luminance Luminance
2 Saturation Saturation
3Hue Hue
4DensityDensity
