Sony XVS Series - 4 K Format Restrictions

461
4K Format Restrictions
In 4K format, the following function and settings
restrictions apply.
a) You can change the M/E banks that are to be disabled in the Engineering
Setup >Switcher >Config >Logical M/E Assign menu (7331.5).
Sub key restrictions
In 4K format, key 3 and key 4 are called “sub keys,” and
the following function and settings restrictions apply.
You can set the sub key mode in the Setup menu (see
page 403).
Item Restrictions
Functions that
cannot be used in
the switcher
• M/E-5 bank
a)
•Key 5 to key 8
• M/E Config multi-program mode
and multi-program 2 mode
• Utility 1 and 2 buses
• AUX11 to AUX48 buses
• Side flags
DMEs All functions relating to DMEs not
supported
Screen aspect Fixed to 16:9
Transitions • Clip transitions not supported
• Preset color mix using Utility 2 bus
not supported
• When key 1 (key 2) is selected for
the next transition and DME wipe is
selected as the transition type, key
1 (key 2) independent key transition
wipes not supported
Keys • Key 3 and key 4 function as sub
keys
• Wipe pattern keys not supported
• Filter parameter settings for
luminance keys, linear keys, and
chroma keys not supported
• Y Filter and C Filter parameters for
color vector keys not supported
• [Key Position] settings for
luminance keys, linear keys, and
chroma keys not supported
• Filter parameter settings for color
cancel key of chroma keys not
supported
• [Key Position] settings for color
cancel key of chroma keys not
supported
• [Shadow] settings for chroma keys
not supported
• [Edge Blink] blinking not supported
• Edge and submask settings not
supported
• PROC V and PROC K signals not
supported
Resizer Dual resizer effects not supported
DME wipes Only resizer DME wipe patterns are
supported
Frame memory All functions relating to frame memory
not supported
Safe titles Outputs with active area of
4096×2160 not supported
Color background Color background 2 not supported
Note
Item Restrictions
Transitions Independent key transitions only are
supported
However, the following settings are
not supported.
• Wipe transition type
• DME wipe transition type
Key settings Luminance key and linear key only
are supported
However, the following settings are
not supported.
• Filter parameter
• [Key Position]
• [Mix Color] in the <Fill Matte> group
•Edge
•Mask
•Blink
Key material Primary input, black, white, and color
background signals only are
supported
However, NMI input signals not
supported
Key priority Priority settings not supported
(After key 1 and key 2, the sequence
key 3 - key 4 is fixed.)
Resizer Resizer not supported
Key preview/Show
key
Key 3 only supported when the sub
key is set to [Key3 + Key PVW].
