[Video] and [Key] can also be selected at the same
time.
[Video] and [Key] cannot be deselected at the same
time. One or the other is always selected.
4
Select the signal to assign.
5
In the <Xpt Assign> group, select one of the
following.
Set: Delete the signal currently assigned to the
selected button number and make a new
assignment.
Insert: Move the signal currently assigned to the
selected button number to the next number, and
make a new assignment.
To inhibit operation of buttons
Select the target button number to set, and press [Inhibit].
To delete a signal assigned to a button
Select the button number, and press [Delete] in the <Xpt
Assign> group.
The signals assigned to numbers following the selected
button number move up in sequence.
Creating tables 1 to 14
You create tables 1 to 14 in the same way as when creating
the main table, and you can assign the same signal to more
than one button number, or delete currently assigned
signals. However, assignment of video and key
combinations as a pair is not possible.
1
In the Engineering Setup >Panel >Xpt Assign menu
(7322), press [Table Button Assign].
The Table Button Assign menu (7322.1) appears.
The target table number to set appears in the upper left
of the status area.
The left part of the status area shows the cross-point
button numbers, video and key pair numbers, video
signal source names and source numbers, and key
signal source names and source numbers. When the
shift button is pressed, the number field is
distinguished by color.
The right part of the status area shows the video and
key pair numbers, and the names of video signals and
key signals set in the main table.
2
Select the target table to set.
3
Select the target button number to set.
4
Select the pair signal to assign.
5
In the <Button Assign> group, select one of the
following.
Set: Delete the signal currently assigned to the
selected button number and make a new
assignment.
Insert: Move the signal currently assigned to the
selected button number to the next number, and
make a new assignment.
To inhibit operation of buttons
Select the target button number to set, and press [Inhibit].
To delete a signal assigned to a button
Select the button number, and press [Delete] in the
<Button Assign> group.
The signals assigned to numbers following the selected
button number move up in sequence.
Returning a table to defaults
1
In the Engineering Setup >Panel >Xpt Assign >Main,
V/K Pair Assign menu (7322.5) or the Engineering
Setup >Panel >Xpt Assign >Table Button Assign
menu (7322.1), press [Default Recall].
2
Check the message, then press [Yes].
Setting the [SHIFT] button operation mode
This sets the operation of the [SHIFT] button assigned to
the right edge of the cross-point button row. The setting
can be configured for each cross-point assign table (main,
1 to 14).
The operation of the [SHIFT] button in the 2nd row of the
cross-point control block in key/AUX bus delegation
mode is the operation mode set by the cross-point assign
table assigned to the switcher bank (M/E or P/P),
regardless of the bus selected in the 1st row.
1
In the Engineering Setup >Panel >Xpt Assign >Main,
V/K Pair Assign menu (7322.5) or the Engineering
Setup >Panel >Xpt Assign >Table Button Assign
menu (7322.1), press [Shift Mode].
The Shift Mode menu (7322.13) appears.
2
Select the target table to set.
3
In the <Xpt Shift Mode> group, select the operation
mode of the [SHIFT] button.
No. Parameter Adjustment
3 Source No Selection of signal to assign
No. Parameter Adjustment
1 Table No Selection of the table to set
