Sony XVS Series

386
a) The safe title enable/disable commands display the name of the signal assigned to the output.
M/Ex PVW M/E-x preview output
x = 1 to 5
Output on the edit
preview bus
Function assigned
M/Ex KPVW1 M/E-x key preview 1 output
x = 1 to 5
Output on the edit
preview bus
Function assigned
M/Ex KPVW2 M/E-x key preview 2 output
x = 1 to 5
Output on the edit
preview bus
Function assigned
P/P PVW P/P preview output Output on the edit
preview bus
Function assigned
P/P KPVW1 P/P key preview 1 output Output on the edit
preview bus
Function assigned
P/P KPVW2 P/P key preview 2 output Output on the edit
preview bus
Function assigned
AUTO PVW Auto preview Output on the edit
preview bus
Function assigned
PRESET PVW Preset preview Output on the edit
preview bus
Function assigned
DCU GPI1 Test Fire
|
DCU GPI50 Test Fire
Test trigger output from port assigned
to DCU GPI1
|
Test trigger output from port assigned
to DCU GPI50
Output (lit only at the
instant the button is
pressed)
Output assigned
Macro Attachment Enbl Macro attachment enable/disable Enabled Disabled
Pre Macro Sets macro attachment in pre macro
mode.
Can be set only while
pressed (lit)
Function assigned
Post Macro Sets macro attachment in post macro
mode.
Can be set only while
pressed (lit)
Function assigned
Macro Take Macro execution Pause during
execution
Function assigned
Macro Cancel Macro cancel Lit only at the instant
the button is pressed
Function assigned
Macro Auto Ins Macro auto insert mode enable/disable Enabled Disabled
Macro AT with Rate Mode enable/disable for storing
transition rate when registering an auto
transition macro event on the transition
control block or transition control block
(simple type)
Enabled Disabled
Macro AT with A/B Bus Mode enable/disable for storing A/B
bus cross-points when registering an
auto transition macro event on the
transition control block or transition
control block (simple type)
Enabled Disabled
Macro TL with Region Mode enable disable for saving target
regions when registering a timeline
macro event
Enabled Disabled
DME Override DME override enable/disable Enabled Disabled
DME Graphic DME graphics enable/disable
(applies to graphics for channel
selected in device control block)
Enabled Disabled
FTB Fade-to-black execution Executing Function assigned
Inhibit Set Inhibit cross-point button Can be set only while
pressed (lit)
Function assigned
Inhibit All Clear Clear all cross-point button inhibit
settings
Can be set only while
pressed (lit)
Function assigned
Command name Function Button state
Lit amber Off
