Sony XVS Series

388
PP PVW ST
a)
P/P preview output safe title enable/
disable
Enabled Disabled
PP Clean ST
a)
P/P clean output safe title enable/
disable
Enabled Disabled
PP K-PVW ST
a)
P/P key preview output safe title
enable/disable
Enabled Disabled
DME Mon Video ST
a)
DME Monitor Video output safe title
enable/disable
Enabled Disabled
DME Mon Key ST
a)
DME Monitor Key output safe title
enable/disable
Enabled Disabled
Edit PVW ST
a)
Edit preview output safe title enable/
disable
Enabled Disabled
Preset ST
a)
Preset output safe title enable/disable Enabled Disabled
AUX1 ST
a)
|
AUX48 ST
a)
AUX1 output safe title enable/disable
|
AUX48 output safe title enable/disable
Enabled Disabled
M/Ex PVW M/E-x preview output
x = 1 to 5
Output on the edit
preview bus
Function assigned
M/Ex KPVW1 M/E-x key preview 1 output
x = 1 to 5
Output on the edit
preview bus
Function assigned
M/Ex KPVW2 M/E-x key preview 2 output
x = 1 to 5
Output on the edit
preview bus
Function assigned
P/P PVW P/P preview output Output on the edit
preview bus
Function assigned
P/P KPVW1 P/P key preview 1 output Output on the edit
preview bus
Function assigned
P/P KPVW2 P/P key preview 2 output Output on the edit
preview bus
Function assigned
AUTO PVW Auto preview Output on the edit
preview bus
Function assigned
PRESET PVW Preset preview Output on the edit
preview bus
Function assigned
DCU GPI1 Test Fire
|
DCU GPI50 Test Fire
Output test trigger from port assigned
to DCU GPI1
|
Output test trigger from port assigned
to DCU GPI50
Output (lit only at the
instant the button is
pressed)
Output assigned
Macro Attachment Enbl Macro attachment enable/disable Enabled Disabled
Pre Macro Sets macro attachment in pre macro
mode.
Can be set only while
pressed (lit)
Function assigned
Post Macro Sets macro attachment in post macro
mode.
Can be set only while
pressed (lit)
Function assigned
Macro Take Macro execution Lit light purple during
execution
Lit purple during
pause
Function assigned
(gray characters
displayed on black
background)
Macro Cancel Macro cancel Lit only at the instant
the button is pressed
Function assigned
Macro Auto Ins Macro auto insert mode enable/disable Enabled Disabled
Macro AT with Rate Mode enable/disable for storing
transition rate when registering an
auto transition macro event on the
transition control block or transition
control block (simple type)
Enabled Disabled
Command name Function Button state
Lit orange Lit dark blue
