Control block Bus name Cross-point button
rows
Delegation operation
a)
Cross-point
control block:
M/E-1
M/E-2
M/E-3
M/E-4
M/E-5
PGM/PST
Background A bus
b) c)
3rd row –
Background B bus
b) c)
4th row –
Key 1 bus to key 8 bus
c)
1st row, 2nd row • Press the delegation buttons [KEY1] to [KEY8]
on the cross-point pad, turning them on.
• To assign to the 2nd row in key/AUX bus
delegation mode, press the [KEY1] to [KEY8]
buttons in the 1st row, turning them on.
Utility 1 bus
c)
Utility 2 bus
c)
1st row, 2nd row • Press the delegation buttons [UTL1] and
[UTL2] on the cross-point pad, turning them
on.
• To assign to the 2nd row in key/AUX bus
delegation mode, press the [UTIL1] and
[UTIL2] buttons in the 1st row, turning them
on.
DME external video bus
c)
1st row, 2nd row • Press the delegation button [DME EXT] on the
cross-point pad, turning it on.
• To assign to the 2nd row in key/AUX bus
delegation mode, press the [DME EXT] button
in the 1st row, turning it on.
DME utility 1 bus
c)
DME utility 2 bus
c)
1st row, 2nd row • Press the delegation buttons [DME UTL1] and
[DME UTL2] on the cross-point pad, turning
them on.
• To assign to the 2nd row in key/AUX bus
delegation mode, press the [DME UTIL1] and
[DME UTIL2] buttons in the 1st row, turning
them on.
Edit preview bus 2nd row In key/AUX bus delegation mode, press the
[EDIT PVW] button in the 1st row, turning it on.
AUX1 bus to AUX48 bus 2nd row In key/AUX bus delegation mode, press the
[AUX 1] to [AUX 48] buttons in the 1st row,
turning them on.
Frame memory source 1 bus
Frame memory source 2 bus
2nd row In key/AUX bus delegation mode, press the
[FMS 1] and [FMS 2] buttons in the 1st row,
turning them on.
DME1 video bus to DME4 video
bus
2nd row In key/AUX bus delegation mode, press the
[DME1 V] to [DME4 V] buttons in the 1st row,
turning them on.
DME1 key bus to DME4 key bus 2nd row In key/AUX bus delegation mode, press the
[DME1 K] to [DME4 K] buttons in the 1st row,
turning them on.
Color corrector 1 bus
Color corrector 2 bus
2nd row In key/AUX bus delegation mode, press the
[CCR 1] and [CCR 2] buttons in the 1st row,
turning them on.
