Recording Recording mode of the fader (in the Vistonics™ generic display area):
Characters without a frame indicate the status of the fader (I = Isolate, R =
Read, T = Trim, W = Write).
A red frame behind the W or T indicates that the rotary control is currently
recording.
n–1 x n–1 x indicates that the channel is the owner of an n–1 bus, together with its
bus number - e.g. ‘m 1’ for ‘mono 1’.
Rotary Dynamic/Static Dynamic/static view of the rotary control:
When clicking the View Dyn button in the ACU window, this display changes
to DYN, if this control contains dynamically automated elements
Fader Dynamic/Static Dynamic/static view of the fader: When clicking the View Dyn button in the
ACU window, this display appears and indicates FADER DYN, if the fader
is dynamically automated.
