Note

The encoder ports are connected by a multiplexer to the same circuits as the integrated encoders. This

means that if external encoder 1 is used, integrated encoder 1 can not be used. External encoder 2

can be used with ABI or HALL only when the integrated encoder 2 is used.

Please refer to the following image for details:

1.2.6.2.1.2.3.1 External Encoder 1

Circulo 7
