Note

This connector also carries the pins for the battery that is required if the optional integrated encoder 1 is

used with Multi-Turn. For selecting a suitable battery, please check these notes.

Attention

If the integrated encoder 1 is used, the external encoder 1 can not be used.

Protocol/Function Multi turn

battery supply
