1.2.6.2.1.4.2.2 STO/SBC Connections

Wire # Function

1 STO-SBC1

2 STO-SBC2

3 Safety Ground

Note

On the Y-Splitter cable these wires are open strands at the master side.

1.2.6.2.1.4.2.3 EtherCAT Connection

Note

The Pins in the table below are the standard pins of a RJ45 while the red numbers in the image indicate

the reference pins of the hybrid connector.

Pin # Function

1 TX_P

2 TX_N

3 RX_P
