Circulo 9
Connector description Manufacturer Mating part Crimping
Contact
Wire Gauge
Digital IO JST Sales
America
GHR-11V-S SSHL-002T-P0.2
[1]
28 AWG
External Encoder 1 JST Sales
America
GHR-07V-S SSHL-002T-P0.2
[1]
28 AWG
External Encoder 2 JST Sales
America
GHR-10V-S SSHL-002T-P0.2
[1]
28 AWG
Analog In JST Sales
America
GHR-06V-S SSHL-002T-P0.2
[1]
28 AWG
Temperature Sensor JST Sales
America
GHR-02V-S SSHL-002T-P0.2
[1]
28 AWG
EtherCAT/STO-SBC In /
Out
JST Sales
America
GHR-08V-S Customized cable 28-32 AWG
Brake Connector JST Sales
America
ZER-02V-S SZE-002T-P0.3
[2]
28 AWG
24V-48V Supply TE Connectivity 4-520448-2
[3]
4-520447-2
[4]
10-12 AWG
24V-48V Supply
(piggyback)
[6]
Molex 0190130033
[3]
10-12 AWG
Motor Phases Molex 0190070040
[3]
0190070041
[4]
10-12 AWG
[1]
[2]
[3]
[4]
[5]
[6]
Crimped cable from JST Sales America can be used, Parts number: AGHGH28K305
Crimped cable from JST Sales America can be used, Parts number: ASZESZE26K305
These terminals are in loose-piece for terminating with manual hand-held tools.
These terminals are in strip version for feeder machines.
This connector isn’t UL certified
With piggyback connectors, the connections will be out of Circulo diameter. Please consider this in your
mechanical design!
