Sysmex XP-300 5-9
Initial Operation
Revised July 2012
Connect STROMATOLYSER-WH
(1) Gently remove the dust-protection bag containing the Float Switch No. 23 Assy that is
connected to the main unit.
(2) Install the float switch to STROMATOLYSER-WH. Then, set it on to the table.
Connect waste line
(1) Prepare the following waste line tube.
Tube Polyurethane 6 mm ID × 9 mm OD....... 1 pc
(2) Connect an end of the tube polyurethane to the drain outlet nipple behind the unit. Connect the
other end of the tube to the waste sewer in the lab.
If the waste sewer is not available, connect it to a waste tank.
STROMATOLYSER-WH
Float Switch No. 23 Assy
• Cut the tube to an appropriate length, and connect it.
• The maximum waste line length is 6 m. Since waste is removed from the system by
pressurized air, the waste tank may be located at the same height as, or lower than, the drain
outlet nipple. Otherwise the waste may flow back into the system, which will result in a
malfunction.
To Next Page
