Sysmex XP-300 6-3
Operation
Revised July 2012
Action message screen
This screen appears when an error has occurred and the
button
has been pressed.
Follow the instructions on this screen to easily perform a recovery
process.
Dialog screen
Dialog includes the “Error dialog” when errors occur, the
“Confirmation dialog” when settings are changed, and the
“Numerical keys dialog” for entering numerals.
Dialog appears at the top of the screen displayed at that time. Buttons
at the bottom of the screen are inactive at this time.
Error dialog
Confirmation dialog
Display column
The Main screen sample ID, setting values, and other items which
can be changed by the operator appear as white boxes with shadows.
These boxes are referred to as “display columns” in the Instructions
for Use.
Press on a display column to input information.
Selections
For settings which require the selection of one setting from multiple
options, the options are displayed when the display column is
pressed. Press the selection to input that value. If all of the options
cannot be displayed on the screen, the [more] button is displayed in
the options area. Press the [more] button to change the displayed
options.
Type 1
Type 1
Type 2
Type 3
Type 4
more
