Peripherals used for booting, like I2C and HPI, are automatically enabled after device reset. It is not
possible to disable these peripherals after the boot process is complete.
The C64x+ Megamodule also allows for software-driven power-down management for all of the C64x+
megamodule components through its Power-Down Controller (PDC). The CPU can power-down part or
the entire C64x+ megamodule through the power-down controller based on its own execution thread or in
response to an external stimulus from a host or global controller. More information on the power-down
features of the C64x+ Megamodule can be found in the TMS320C64x+ Megamodule Reference Guide
(literature number SPRU871).
7.3.4 Preserving Boundary-Scan Functionality on RGMII and DDR2 Memory Pins
When the RGMII mode of the EMAC is not used, the DV
DD15
, DV
DD15MON
, V
REFHSTL
, RSV13, and RSV14
pins can be connected directly to ground (V
SS
) to save power. However, this will prevent boundary-scan
from functioning on the RGMII pins of the EMAC. To preserve boundary-scan functionality on the RGMII
pins, DV
DD15
, V
REFHSTL
, RSV14, and RSV13 should be connected as follows:
• DV
DD15
and DV
DD15MON
- connect these pins to the 1.8-V I/O supply (DV
DD18
).
• V
REFHSTL
- connect to a voltage of DV
DD18
/2. The DV
DD18
/2 voltage can be generated directly from the
DV
DD18
supply using two 1-kΩ resistors to form a resistor divider circuit.
• RSV13 - connect this pin to ground (V
SS
) via a 200-Ω resistor.
• RSV14 - connect this pin to the 1.8-V I/O supply (DV
DD18
) via a 200-Ω resistor.
Similarly, when the DDR2 Memory Controller is not used, the V
REFSSTL
, RSV11, and RSV12 pins can be
connected directly to ground (V
SS
) to save power. However, this will prevent boundary-scan from
functioning on the DDR2 Memory Controller pins. To preserve boundary-scan functionality on the DDR2
Memory Controller pins, V
REFSSTL
, RSV11, and RSV12 should be connected as follows:
• V
REFSSTL
- connect to a voltage of DV
DD18
/2. The DV
DD18
/2 voltage can be generated directly from the
DV
DD18
supply using two 1-kΩ resistors to form a resistor divider circuit.
• RSV11 - connect this pin to ground (V
SS
) via a 200-Ω resistor.
• RSV12 - connect this pin to the 1.8-V I/O supply (DV
DD18
) via a 200-Ω resistor.
104 C64x+ Peripheral Information and Electrical Specifications Copyright © 2005–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
