TMS320C6455
www.ti.com SPRS276M –MAY 2005–REVISED MARCH 2012
Table 7-6. EDMA3 Transfer Controller 0 Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02A2 0288 DFDSTBREF Destination FIFO Set Destination Address B Reference Register
02A2 028C - 02A2 02FC - Reserved
02A2 0300 DFOPT0 Destination FIFO Options Register 0
02A2 0304 DFSRC0 Destination FIFO Source Address Register 0
02A2 0308 DFCNT0 Destination FIFO Count Register 0
02A2 030C DFDST0 Destination FIFO Destination Address Register 0
02A2 0310 DFBIDX0 Destination FIFO BIDX Register 0
02A2 0314 DFMPPRXY0 Destination FIFO Memory Protection Proxy Register 0
02A2 0318 - 02A2 033C - Reserved
02A2 0340 DFOPT1 Destination FIFO Options Register 1
02A2 0344 DFSRC1 Destination FIFO Source Address Register 1
02A2 0348 DFCNT1 Destination FIFO Count Register 1
02A2 034C DFDST1 Destination FIFO Destination Address Register 1
02A2 0350 DFBIDX1 Destination FIFO BIDX Register 1
02A2 0354 DFMPPRXY1 Destination FIFO Memory Protection Proxy Register 1
02A2 0358 - 02A2 037C - Reserved
02A2 0380 DFOPT2 Destination FIFO Options Register 2
02A2 0384 DFSRC2 Destination FIFO Source Address Register 2
02A2 0388 DFCNT2 Destination FIFO Count Register 2
02A2 038C DFDST2 Destination FIFO Destination Address Register 2
02A2 0390 DFBIDX2 Destination FIFO BIDX Register 2
02A2 0394 DFMPPRXY2 Destination FIFO Memory Protection Proxy Register 2
02A2 0398 - 02A2 03BC - Reserved
02A2 03C0 DFOPT3 Destination FIFO Options Register 3
02A2 03C4 DFSRC3 Destination FIFO Source Address Register 3
02A2 03C8 DFCNT3 Destination FIFO Count Register 3
02A2 03CC DFDST3 Destination FIFO Destination Address Register 3
02A2 03D0 DFBIDX3 Destination FIFO BIDX Register 3
02A2 03D4 DFMPPRXY3 Destination FIFO Memory Protection Proxy Register 3
02A2 03D8 - 02A2 7FFF - Reserved
Table 7-7. EDMA3 Transfer Controller 1 Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02A2 8000 PID Peripheral Identification Register
02A2 8004 TCCFG EDMA3TC Configuration Register
02A2 8008 - 02A2 80FC - Reserved
02A2 8100 TCSTAT EDMA3TC Channel Status Register
02A2 8104 - 02A2 811C - Reserved
02A2 8120 ERRSTAT Error Register
02A2 8124 ERREN Error Enable Register
02A2 8128 ERRCLR Error Clear Register
02A2 812C ERRDET Error Details Register
02A2 8130 ERRCMD Error Interrupt Command Register
02A2 8134 - 02A2 813C - Reserved
02A2 8140 RDRATE Read Rate Register
02A2 8144 - 02A2 823C - Reserved
02A2 8240 SAOPT Source Active Options Register
Copyright © 2005–2012, Texas Instruments Incorporated C64x+ Peripheral Information and Electrical Specifications 115
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
