TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012
www.ti.com
Table 5-4. Megamodule Interrupt Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0180 0188 INTDMASK Dropped Interrupt Mask Register
0180 0188 - 0180 01BC - Reserved
0180 01C0 EVTASRT Event Asserting Register
0180 01C4 - 0180 FFFF - Reserved
Table 5-5. Megamodule Powerdown Control Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0181 0000 PDCCMD Power-down controller command register
0181 0004 - 0181 1FFF - Reserved
Table 5-6. Megamodule Revision Register
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0181 2000 MM_REVID Megamodule Revision ID Register
0181 2004 - 0181 2FFF - Reserved
Table 5-7. Megamodule IDMA Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0182 0000 IDMA0STAT IDMA Channel 0 Status Register
0182 0004 IDMA0MASK IDMA Channel 0 Mask Register
0182 0008 IMDA0SRC IDMA Channel 0 Source Address Register
0182 000C IDMA0DST IDMA Channel 0 Destination Address Register
0182 0010 IDMA0CNT IDMA Channel 0 Count Register
0182 0014 - 0182 00FC - Reserved
0182 0100 IDMA1STAT IDMA Channel 1 Status Register
0182 0104 - Reserved
0182 0108 IMDA1SRC IDMA Channel 1 Source Address Register
0182 010C IDMA1DST IDMA Channel 1 Destination Address Register
0182 0110 IDMA1CNT IDMA Channel 1 Count Register
0182 0114 - 0182 017C - Reserved
0182 0180 - Reserved
0182 0184 - 0182 01FF - Reserved
90 C64x+ Megamodule Copyright © 2005–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
