TMS320C6455
www.ti.com SPRS276M –MAY 2005–REVISED MARCH 2012
Table 7-4. EDMA3 Channel Controller Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02A0 0490 Q2E4 Event Queue 2 Entry Register 4
02A0 0494 Q2E5 Event Queue 2 Entry Register 5
02A0 0498 Q2E6 Event Queue 2 Entry Register 6
02A0 049C Q2E7 Event Queue 2 Entry Register 7
02A0 04A0 Q2E8 Event Queue 2 Entry Register 8
02A0 04A4 Q2E9 Event Queue 2 Entry Register 9
02A0 04A8 Q2E10 Event Queue 2 Entry Register 10
02A0 04AC Q2E11 Event Queue 2 Entry Register 11
02A0 04B0 Q2E12 Event Queue 2 Entry Register 12
02A0 04B4 Q2E13 Event Queue 2 Entry Register 13
02A0 04B8 Q2E14 Event Queue 2 Entry Register 14
02A0 04BC Q2E15 Event Queue 2 Entry Register 15
02A0 04C0 Q3E0 Event Queue 3 Entry Register 0
02A0 04C4 Q3E1 Event Queue 3 Entry Register 1
02A0 04C8 Q3E2 Event Queue 3 Entry Register 2
02A0 04CC Q3E3 Event Queue 3 Entry Register 3
02A0 04D0 Q3E4 Event Queue 3 Entry Register 4
02A0 04D4 Q3E5 Event Queue 3 Entry Register 5
02A0 04D8 Q3E6 Event Queue 3 Entry Register 6
02A0 04DC Q3E7 Event Queue 3 Entry Register 7
02A0 04E0 Q3E8 Event Queue 3 Entry Register 8
02A0 04E4 Q3E9 Event Queue 3 Entry Register 9
02A0 04E8 Q3E10 Event Queue 3 Entry Register 10
02A0 04EC Q3E11 Event Queue 3 Entry Register 11
02A0 04F0 Q3E12 Event Queue 3 Entry Register 12
02A0 04F4 Q3E13 Event Queue 3 Entry Register 13
02A0 04F8 Q3E14 Event Queue 3 Entry Register 14
02A0 04FC Q3E15 Event Queue 3 Entry Register 15
02A0 0500 - 02A0 051C - Reserved
02A0 0520 - 02A0 05FC - Reserved
02A0 0600 QSTAT0 Queue Status Register 0
02A0 0604 QSTAT1 Queue Status Register 1
02A0 0608 QSTAT2 Queue Status Register 2
02A0 060C QSTAT3 Queue Status Register 3
02A0 0610 - 02A0 061C - Reserved
02A0 0620 QWMTHRA Queue Watermark Threshold A Register
02A0 0624 - 02A0 063C - Reserved
02A0 0640 CCSTAT EDMA3CC Status Register
02A0 0644 - 02A0 06FC - Reserved
02A0 0700 - 02A0 07FC - Reserved
02A0 0800 MPFAR Memory Protection Fault Address Register
02A0 0804 MPFSR Memory Protection Fault Status Register
02A0 0808 MPFCR Memory Protection Fault Command Register
02A0 080C MPPA0 Memory Protection Page Attribute Register 0
02A0 0810 MPPA1 Memory Protection Page Attribute Register 1
02A0 0814 MPPA2 Memory Protection Page Attribute Register 2
02A0 0818 MPPA3 Memory Protection Page Attribute Register 3
