7.14.2 EMAC Peripheral Register Descriptions
Table 7-71. Ethernet MAC (EMAC) Control Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02C8 0000 TXIDVER Transmit Identification and Version Register
02C8 0004 TXCONTROL Transmit Control Register
02C8 0008 TXTEARDOWN Transmit Teardown Register
02C8 000F - Reserved
02C8 0010 RXIDVER Receive Identification and Version Register
02C8 0014 RXCONTROL Receive Control Register
02C8 0018 RXTEARDOWN Receive Teardown Register
02C8 001C - Reserved
02C8 0020 - 02C8 007C - Reserved
02C8 0080 TXINTSTATRAW Transmit Interrupt Status (Unmasked) Register
02C8 0084 TXINTSTATMASKED Transmit Interrupt Status (Masked) Register
02C8 0088 TXINTMASKSET Transmit Interrupt Mask Set Register
02C8 008C TXINTMASKCLEAR Transmit Interrupt Mask Clear Register
02C8 0090 MACINVECTOR MAC Input Vector Register
02C8 0094 - 02C8 009C - Reserved
02C8 00A0 RXINTSTATRAW Receive Interrupt Status (Unmasked) Register
02C8 00A4 RXINTSTATMASKED Receive Interrupt Status (Masked) Register
02C8 00A8 RXINTMASKSET Receive Interrupt Mask Set Register
02C8 00AC RXINTMASKCLEAR Receive Interrupt Mask Clear Register
02C8 00B0 MACINTSTATRAW MAC Interrupt Status (Unmasked) Register
02C8 00B4 MACINTSTATMASKED MAC Interrupt Status (Masked) Register
02C8 00B8 MACINTMASKSET MAC Interrupt Mask Set Register
02C8 00BC MACINTMASKCLEAR MAC Interrupt Mask Clear Register
02C8 00C0 - 02C8 00FC - Reserved
02C8 0100 RXMBPENABLE Receive Multicast/Broadcast/Promiscuous Channel Enable Register
02C8 0104 RXUNICASTSET Receive Unicast Enable Set Register
02C8 0108 RXUNICASTCLEAR Receive Unicast Clear Register
02C8 010C RXMAXLEN Receive Maximum Length Register
02C8 0110 RXBUFFEROFFSET Receive Buffer Offset Register
02C8 0114 RXFILTERLOWTHRESH Receive Filter Low Priority Frame Threshold Register
02C8 0118 - 02C8 011C - Reserved
02C8 0120 RX0FLOWTHRESH Receive Channel 0 Flow Control Threshold Register
02C8 0124 RX1FLOWTHRESH Receive Channel 1 Flow Control Threshold Register
02C8 0128 RX2FLOWTHRESH Receive Channel 2 Flow Control Threshold Register
02C8 012C RX3FLOWTHRESH Receive Channel 3 Flow Control Threshold Register
02C8 0130 RX4FLOWTHRESH Receive Channel 4 Flow Control Threshold Register
02C8 0134 RX5FLOWTHRESH Receive Channel 5 Flow Control Threshold Register
02C8 0138 RX6FLOWTHRESH Receive Channel 6 Flow Control Threshold Register
02C8 013C RX7FLOWTHRESH Receive Channel 7 Flow Control Threshold Register
02C8 0140 RX0FREEBUFFER Receive Channel 0 Free Buffer Count Register
02C8 0144 RX1FREEBUFFER Receive Channel 1 Free Buffer Count Register
02C8 0148 RX2FREEBUFFER Receive Channel 2 Free Buffer Count Register
02C8 014C RX3FREEBUFFER Receive Channel 3 Free Buffer Count Register
02C8 0150 RX4FREEBUFFER Receive Channel 4 Free Buffer Count Register
02C8 0154 RX5FREEBUFFER Receive Channel 5 Free Buffer Count Register
