Table 7-112. RapidIO Control Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02D0 20E8 RIO_SP2_ERR_RATE Port 2 Error Rate CSR
02D0 20EC RIO_SP2_ERR_THRESH Port 2 Error Rate Threshold CSR
02D0 20F0 - 02D0 20FC - Reserved
02D0 2100 RIO_SP3_ERR_DET Port 3 Error Detect CSR
02D0 2104 RIO_SP3_RATE_EN Port 3 Error Enable CSR
02D0 2108 RIO_SP3_ERR_ATTR_CAPT_DBG0 Port 3 Attributes Error Capture CSR 0
02D0 210C RIO_SP3_ERR_CAPT_DBG1 Port 3 Packet/Control Symbol Error Capture CSR 1
02D0 2110 RIO_SP3_ERR_CAPT_DBG2 Port 3 Packet/Control Symbol Error Capture CSR 2
02D0 2114 RIO_SP3_ERR_CAPT_DBG3 Port 3 Packet/Control Symbol Error Capture CSR 3
02D0 2118 RIO_SP3_ERR_CAPT_DBG4 Port 3 Packet/Control Symbol Error Capture CSR 4
02D0 211C - 02D0 2124 - Reserved
02D0 2128 RIO_SP3_ERR_RATE Port 3 Error Rate CSR
02D0 212C RIO_SP3_ERR_THRESH Port 3 Error Rate Threshold CSR
02D0 2130 - 02D1 0FFC - Reserved
Implementation Registers
02D1 1000 - 02D1 1FFC - Reserved
02D1 2000 RIO_SP_IP_DISCOVERY_TIMER Port IP Discovery Timer in 4x mode
02D1 2004 RIO_SP_IP_MODE Port IP Mode CSR
02D1 2008 RIO_IP_PRESCAL Port IP Prescaler Register
02D1 200C - Reserved
02D1 2010 RIO_SP_IP_PW_IN_CAPT0 Port-Write-In Capture CSR Register 0
02D1 2014 RIO_SP_IP_PW_IN_CAPT1 Port-Write-In Capture CSR Register 1
02D1 2018 RIO_SP_IP_PW_IN_CAPT2 Port-Write-In Capture CSR Register 2
02D1 201C RIO_SP_IP_PW_IN_CAPT3 Port-Write-In Capture CSR Register 3
02D1 2020 - 02D1 3FFC - Reserved
02D1 4000 RIO_SP0_RST_OPT Port 0 Reset Option CSR
02D1 4004 RIO_SP0_CTL_INDEP Port 0 Control Independent Register
02D1 4008 RIO_SP0_SILENCE_TIMER Port 0 Silence Timer Register
02D1 400C RIO_SP0_MULT_EVNT_CS Port 0 Multicast-Event Control Symbol Request Register
02D1 4010 - Reserved
02D1 4014 RIO_SP0_CS_TX Port 0 Control Symbol Transmit Register
02D1 4018 - 02D1 40FC - Reserved
02D1 4100 RIO_SP1_RST_OPT Port 1 Reset Option CSR
02D1 4104 RIO_SP1_CTL_INDEP Port 1 Control Independent Register
02D1 4108 RIO_SP1_SILENCE_TIMER Port 1 Silence Timer Register
02D1 410C RIO_SP1_MULT_EVNT_CS Port 1 Multicast-Event Control Symbol Request Register
02D1 4110 - Reserved
02D1 4114 RIO_SP1_CS_TX Port 1 Control Symbol Transmit Register
02D1 4118 - 02D1 41FC - Reserved
02D1 4200 RIO_SP2_RST_OPT Port 2 Reset Option CSR
02D1 4204 RIO_SP2_CTL_INDEP Port 2 Control Independent Register
02D1 4208 RIO_SP2_SILENCE_TIMER Port 2 Silence Timer Register
02D1 420C RIO_SP2_MULT_EVNT_CS Port 2 Multicast-Event Control Symbol Request Register
02D1 4214 RIO_SP2_CS_TX Port 2 Control Symbol Transmit Register
02D1 4218 - 02D1 42FC - Reserved
02D1 4300 RIO_SP3_RST_OPT Port 3 Reset Option CSR
02D1 4304 RIO_SP3_CTL_INDEP Port 3 Control Independent Register
