TMS320C6455
www.ti.com
SPRS276M –MAY 2005–REVISED MARCH 2012
Table 5-9. Megamodule L1/L2 Memory Protection Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0184 A644 L1PMPPA17 L1P memory protection page attribute register 17
0184 A648 L1PMPPA18 L1P memory protection page attribute register 18
0184 A64C L1PMPPA19 L1P memory protection page attribute register 19
0184 A650 L1PMPPA20 L1P memory protection page attribute register 20
0184 A654 L1PMPPA21 L1P memory protection page attribute register 21
0184 A658 L1PMPPA22 L1P memory protection page attribute register 22
0184 A65C L1PMPPA23 L1P memory protection page attribute register 23
0184 A660 L1PMPPA24 L1P memory protection page attribute register 24
0184 A664 L1PMPPA25 L1P memory protection page attribute register 25
0184 A668 L1PMPPA26 L1P memory protection page attribute register 26
0184 A66C L1PMPPA27 L1P memory protection page attribute register 27
0184 A670 L1PMPPA28 L1P memory protection page attribute register 28
0184 A674 L1PMPPA29 L1P memory protection page attribute register 29
0184 A678 L1PMPPA30 L1P memory protection page attribute register 30
0184 A67C L1PMPPA31 L1P memory protection page attribute register 31
0184 A680 - 0184 ABFF - Reserved
0184 AC00 L1DMPFAR L1 data (L1D) memory protection fault address register
0184 AC04 L1DMPFSR L1D memory protection fault status register
0184 AC08 L1DMPFCR L1D memory protection fault command register
0184 AC0C - 0184 ACFF - Reserved
0184 AD00 L1DMPLK0 L1D memory protection lock key bits [31:0]
0184 AD04 L1DMPLK1 L1D memory protection lock key bits [63:32]
0184 AD08 L1DMPLK2 L1D memory protection lock key bits [95:64]
0184 AD0C L1DMPLK3 L1D memory protection lock key bits [127:96]
0184 AD10 L1DMPLKCMD L1D memory protection lock key command register
0184 AD14 L1DMPLKSTAT L1D memory protection lock key status register
0184 AD18 - 0184 ADFF - Reserved
0184 AE00 - 0184 AE3C
(3)
- Reserved
0184 AE40 L1DMPPA16 L1D memory protection page attribute register 16
0184 AE44 L1DMPPA17 L1D memory protection page attribute register 17
0184 AE48 L1DMPPA18 L1D memory protection page attribute register 18
0184 AE4C L1DMPPA19 L1D memory protection page attribute register 19
0184 AE50 L1DMPPA20 L1D memory protection page attribute register 20
0184 AE54 L1DMPPA21 L1D memory protection page attribute register 21
0184 AE58 L1DMPPA22 L1D memory protection page attribute register 22
0184 AE5C L1DMPPA23 L1D memory protection page attribute register 23
0184 AE60 L1DMPPA24 L1D memory protection page attribute register 24
0184 AE64 L1DMPPA25 L1D memory protection page attribute register 25
0184 AE68 L1DMPPA26 L1D memory protection page attribute register 26
0184 AE6C L1DMPPA27 L1D memory protection page attribute register 27
0184 AE70 L1DMPPA28 L1D memory protection page attribute register 28
0184 AE74 L1DMPPA29 L1D memory protection page attribute register 29
0184 AE78 L1DMPPA30 L1D memory protection page attribute register 30
0184 AE7C L1DMPPA31 L1D memory protection page attribute register 31
0184 AE80 - 0185 FFFF - Reserved
(3) These addresses correspond to the L1D memory protection page attribute registers 0-15 (L1DMPPA0-L1DMPPA15) of the C64x+
megamaodule. These registers are not supported for the C6455 device.
Copyright © 2005–2012, Texas Instruments Incorporated C64x+ Megamodule 95
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
