TMS320C6455
www.ti.com SPRS276M –MAY 2005–REVISED MARCH 2012
Table 7-8. EDMA3 Transfer Controller 2 Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02A3 0100 TCSTAT EDMA3TC Channel Status Register
02A3 0104 - 02A3 011C - Reserved
02A3 0120 ERRSTAT Error Register
02A3 0124 ERREN Error Enable Register
02A3 0128 ERRCLR Error Clear Register
02A3 012C ERRDET Error Details Register
02A3 0130 ERRCMD Error Interrupt Command Register
02A3 0134 - 02A3 013C - Reserved
02A3 0140 RDRATE Read Rate Register
02A3 0144 - 02A3 023C - Reserved
02A3 0240 SAOPT Source Active Options Register
02A3 0244 SASRC Source Active Source Address Register
02A3 0248 SACNT Source Active Count Register
02A3 024C SADST Source Active Destination Address Register
02A3 0250 SABIDX Source Active Source B-Index Register
02A3 0254 SAMPPRXY Source Active Memory Protection Proxy Register
02A3 0258 SACNTRLD Source Active Count Reload Register
02A3 025C SASRCBREF Source Active Source Address B-Reference Register
02A3 0260 SADSTBREF Source Active Destination Address B-Reference Register
02A3 0264 - 02A3 027C - Reserved
02A3 0280 DFCNTRLD Destination FIFO Set Count Reload
02A3 0284 DFSRCBREF Destination FIFO Set Destination Address B Reference Register
02A3 0288 DFDSTBREF Destination FIFO Set Destination Address B Reference Register
02A3 028C - 02A3 02FC - Reserved
02A3 0300 DFOPT0 Destination FIFO Options Register 0
02A3 0304 DFSRC0 Destination FIFO Source Address Register 0
02A3 0308 DFCNT0 Destination FIFO Count Register 0
02A3 030C DFDST0 Destination FIFO Destination Address Register 0
02A3 0310 DFBIDX0 Destination FIFO BIDX Register 0
02A3 0314 DFMPPRXY0 Destination FIFO Memory Protection Proxy Register 0
02A3 0318 - 02A3 033C - Reserved
02A3 0340 DFOPT1 Destination FIFO Options Register 1
02A3 0344 DFSRC1 Destination FIFO Source Address Register 1
02A3 0348 DFCNT1 Destination FIFO Count Register 1
02A3 034C DFDST1 Destination FIFO Destination Address Register 1
02A3 0350 DFBIDX1 Destination FIFO BIDX Register 1
02A3 0354 DFMPPRXY1 Destination FIFO Memory Protection Proxy Register 1
02A3 0358 - 02A3 037C - Reserved
02A3 0380 DFOPT2 Destination FIFO Options Register 2
02A3 0384 DFSRC2 Destination FIFO Source Address Register 2
02A3 0388 DFCNT2 Destination FIFO Count Register 2
02A3 038C DFDST2 Destination FIFO Destination Address Register 2
02A3 0390 DFBIDX2 Destination FIFO BIDX Register 2
02A3 0394 DFMPPRXY2 Destination FIFO Memory Protection Proxy Register 2
02A3 0398 - 02A3 03BC - Reserved
02A3 03C0 DFOPT3 Destination FIFO Options Register 3
02A3 03C4 DFSRC3 Destination FIFO Source Address Register 3
Copyright © 2005–2012, Texas Instruments Incorporated C64x+ Peripheral Information and Electrical Specifications 117
