Table 7-7. EDMA3 Transfer Controller 1 Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02A2 8244 SASRC Source Active Source Address Register
02A2 8248 SACNT Source Active Count Register
02A2 824C SADST Source Active Destination Address Register
02A2 8250 SABIDX Source Active Source B-Index Register
02A2 8254 SAMPPRXY Source Active Memory Protection Proxy Register
02A2 8258 SACNTRLD Source Active Count Reload Register
02A2 825C SASRCBREF Source Active Source Address B-Reference Register
02A2 8260 SADSTBREF Source Active Destination Address B-Reference Register
02A2 8264 - 02A2 827C - Reserved
02A2 8280 DFCNTRLD Destination FIFO Set Count Reload
02A2 8284 DFSRCBREF Destination FIFO Set Destination Address B Reference Register
02A2 8288 DFDSTBREF Destination FIFO Set Destination Address B Reference Register
02A2 828C - 02A2 82FC - Reserved
02A2 8300 DFOPT0 Destination FIFO Options Register 0
02A2 8304 DFSRC0 Destination FIFO Source Address Register 0
02A2 8308 DFCNT0 Destination FIFO Count Register 0
02A2 830C DFDST0 Destination FIFO Destination Address Register 0
02A2 8310 DFBIDX0 Destination FIFO BIDX Register 0
02A2 8314 DFMPPRXY0 Destination FIFO Memory Protection Proxy Register 0
02A2 8318 - 02A2 833C - Reserved
02A2 8340 DFOPT1 Destination FIFO Options Register 1
02A2 8344 DFSRC1 Destination FIFO Source Address Register 1
02A2 8348 DFCNT1 Destination FIFO Count Register 1
02A2 834C DFDST1 Destination FIFO Destination Address Register 1
02A2 8350 DFBIDX1 Destination FIFO BIDX Register 1
02A2 8354 DFMPPRXY1 Destination FIFO Memory Protection Proxy Register 1
02A2 8358 - 02A2 837C - Reserved
02A2 8380 DFOPT2 Destination FIFO Options Register 2
02A2 8384 DFSRC2 Destination FIFO Source Address Register 2
02A2 8388 DFCNT2 Destination FIFO Count Register 2
02A2 838C DFDST2 Destination FIFO Destination Address Register 2
02A2 8390 DFBIDX2 Destination FIFO BIDX Register 2
02A2 8394 DFMPPRXY2 Destination FIFO Memory Protection Proxy Register 2
02A2 8398 - 02A2 83BC - Reserved
02A2 83C0 DFOPT3 Destination FIFO Options Register 3
02A2 83C4 DFSRC3 Destination FIFO Source Address Register 3
02A2 83C8 DFCNT3 Destination FIFO Count Register 3
02A2 83CC DFDST3 Destination FIFO Destination Address Register 3
02A2 83D0 DFBIDX3 Destination FIFO BIDX Register 3
02A2 83D4 DFMPPRXY3 Destination FIFO Memory Protection Proxy Register 3
02A2 83D8 - 02A2 FFFF - Reserved
Table 7-8. EDMA3 Transfer Controller 2 Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02A3 0000 PID Peripheral Identification Register
02A3 0004 TCCFG EDMA3TC Configuration Register
02A3 0008 - 02A3 00FC - Reserved
