Texas Instruments TMS320C6455 User Manual

TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012 www.ti.com
Table 7-112. RapidIO Control Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02D0 02B0 RIO_DOORBELL3_ICRR DOORBELL3 Interrupt Condition Routing Register
02D0 02B4 RIO_DOORBELL3_ICRR2 DOORBELL 3 Interrupt Condition Routing Register 2
02D0 02B8 - 02D0 02BC - Reserved
02D0 02C0 RIO_RX_CPPI_ICRR Receive CPPI Interrupt Condition Routing Register
02D0 02C4 RIO_RX_CPPI_ICRR2 Receive CPPI Interrupt Condition Routing Register 2
02D0 02C8 - 02D0 02CC - Reserved
02D0 02D0 RIO_TX_CPPI_ICRR Transmit CPPI Interrupt Condition Routing Register
02D0 02D4 RIO_TX_CPPI_ICRR2 Transmit CPPI Interrupt Condition Routing Register 2
02D0 02D8 - 02D0 02DC - Reserved
02D0 02E0 RIO_LSU_ICRR0 LSU Interrupt Condition Routing Register 0
02D0 02E4 RIO_LSU_ICRR1 LSU Interrupt Condition Routing Register 1
02D0 02E8 RIO_LSU_ICRR2 LSU Interrupt Condition Routing Register 2
02D0 02EC RIO_LSU_ICRR3 LSU Interrupt Condition Routing Register 3
02D0 02F0 RIO_ERR_RST_EVNT_ICRR Error, Reset, and Special Event Interrupt Condition Routing
Register
02D0 02F4 RIO_ERR_RST_EVNT_ICRR2 Error, Reset, and Special Event Interrupt Condition Routing
Register 2
02D0 02F8 RIO_ERR_RST_EVNT_ICRR3 Error, Reset, and Special Event Interrupt Condition Routing
Register 3
02D0 02FC - Reserved
02D0 0300 RIO_INTDST0_DECODE INTDST Interrupt Status Decode Register 0
02D0 0304 RIO_INTDST1_DECODE INTDST Interrupt Status Decode Register 1
02D0 0308 RIO_INTDST2_DECODE INTDST Interrupt Status Decode Register 2
02D0 030C RIO_INTDST3_DECODE INTDST Interrupt Status Decode Register 3
02D0 0310 RIO_INTDST4_DECODE INTDST Interrupt Status Decode Register 4
02D0 0314 RIO_INTDST5_DECODE INTDST Interrupt Status Decode Register 5
02D0 0318 RIO_INTDST6_DECODE INTDST Interrupt Status Decode Register 6
02D0 031C RIO_INTDST7_DECODE INTDST Interrupt Status Decode Register 7
02D0 0320 RIO_INTDST0_RATE_CNTL INTDST Interrupt Rate Control Register 0
02D0 0324 RIO_INTDST1_RATE_CNTL INTDST Interrupt Rate Control Register 1
02D0 0328 RIO_INTDST2_RATE_CNTL INTDST Interrupt Rate Control Register 2
02D0 032C RIO_INTDST3_RATE_CNTL INTDST Interrupt Rate Control Register 3
02D0 0330 RIO_INTDST4_RATE_CNTL INTDST Interrupt Rate Control Register 4
02D0 0334 RIO_INTDST5_RATE_CNTL INTDST Interrupt Rate Control Register 5
02D0 0338 RIO_INTDST6_RATE_CNTL INTDST Interrupt Rate Control Register 6
02D0 033C RIO_INTDST7_RATE_CNTL INTDST Interrupt Rate Control Register 7
02D0 0340 - 02D0 03FC - Reserved
02D0 0400 RIO_LSU1_REG0 LSU1 Control Register 0
02D0 0404 RIO_LSU1_REG1 LSU1 Control Register 1
02D0 0408 RIO_LSU1_REG2 LSU1 Control Register 2
02D0 040C RIO_LSU1_REG3 LSU1 Control Register 3
02D0 0410 RIO_LSU1_REG4 LSU1 Control Register 4
02D0 0414 RIO_LSU1_REG5 LSU1 Control Register 5
02D0 0418 RIO_LSU1_REG6 LSU1 Control Register 6
02D0 041C RIO_LSU1_FLOW_MASKS LSU1 Congestion Control Flow Mask Register
02D0 0420 RIO_LSU2_REG0 LSU2 Control Register 0
02D0 0424 RIO_LSU2_REG1 LSU2 Control Register 1
02D0 0428 RIO_LSU2_REG2 LSU2 Control Register 2
236 C64x+ Peripheral Information and Electrical Specifications Copyright © 2005–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
