TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012
www.ti.com
Table 7-4. EDMA3 Channel Controller Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02A0 081C MPPA4 Memory Protection Page Attribute Register 4
02A0 0820 MPPA5 Memory Protection Page Attribute Register 5
02A0 0824 MPPA6 Memory Protection Page Attribute Register 6
02A0 0828 MPPA7 Memory Protection Page Attribute Register 7
02A0 082C - 02A0 0FFC - Reserved
02A0 1000 ER Event Register
02A0 1004 ERH Event Register High
02A0 1008 ECR Event Clear Register
02A0 100C ECRH Event Clear Register High
02A0 1010 ESR Event Set Register
02A0 1014 ESRH Event Set Register High
02A0 1018 CER Chained Event Register
02A0 101C CERH Chained Event Register High
02A0 1020 EER Event Enable Register
02A0 1024 EERH Event Enable Register High
02A0 1028 EECR Event Enable Clear Register
02A0 102C EECRH Event Enable Clear Register High
02A0 1030 EESR Event Enable Set Register
02A0 1034 EESRH Event Enable Set Register High
02A0 1038 SER Secondary Event Register
02A0 103C SERH Secondary Event Register High
02A0 1040 SECR Secondary Event Clear Register
02A0 1044 SECRH Secondary Event Clear Register High
02A0 1048 - 02A0 104C - Reserved
02A0 1050 IER Interrupt Enable Register
02A0 1054 IERH Interrupt Enable High Register
02A0 1058 IECR Interrupt Enable Clear Register
02A0 105C IECRH Interrupt Enable Clear High Register
02A0 1060 IESR Interrupt Enable Set Register
02A0 1064 IESRH Interrupt Enable Set High Register
02A0 1068 IPR Interrupt Pending Register
02A0 106C IPRH Interrupt Pending High Register
02A0 1070 ICR Interrupt Clear Register
02A0 1074 ICRH Interrupt Clear High Register
02A0 1078 IEVAL Interrupt Evaluate Register
02A0 107C - Reserved
02A0 1080 QER QDMA Event Register
02A0 1084 QEER QDMA Event Enable Register
02A0 1088 QEECR QDMA Event Enable Clear Register
02A0 108C QEESR QDMA Event Enable Set Register
02A0 1090 QSER QDMA Secondary Event Register
02A0 1094 QSECR QDMA Secondary Event Clear Register
02A0 1098 - 02A0 1FFF - Reserved
Shadow Region 0 Channel Registers
02A0 2000 ER Event Register
02A0 2004 ERH Event Register High
02A0 2008 ECR Event Clear Register
112 C64x+ Peripheral Information and Electrical Specifications Copyright © 2005–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
