Table 5-8. Megamodule Cache Configuration Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0184 8350 MAR212 Controls EMIFA CE5 Range D400 0000 - D4FF FFFF
0184 8354 MAR213 Controls EMIFA CE5 Range D500 0000 - D5FF FFFF
0184 8358 MAR214 Controls EMIFA CE5 Range D600 0000 - D6FF FFFF
0184 835C MAR215 Controls EMIFA CE5 Range D700 0000 - D7FF FFFF
0184 8360 MAR216 Controls EMIFA CE5 Range D800 0000 - D8FF FFFF
0184 8364 MAR217 Controls EMIFA CE5 Range D900 0000 - D9FF FFFF
0184 8368 MAR218 Controls EMIFA CE5 Range DA00 0000 - DAFF FFFF
0184 836C MAR219 Controls EMIFA CE5 Range DB00 0000 - DBFF FFFF
0184 8370 MAR220 Controls EMIFA CE5 Range DC00 0000 - DCFF FFFF
0184 8374 MAR221 Controls EMIFA CE5 Range DD00 0000 - DDFF FFFF
0184 8378 MAR222 Controls EMIFA CE5 Range DE00 0000 - DEFF FFFF
0184 837C MAR223 Controls EMIFA CE5 Range DF00 0000 - DFFF FFFF
0184 8380 MAR224 Controls DDR2 CE0 Range E000 0000 - E0FF FFFF
0184 8384 MAR225 Controls DDR2 CE0 Range E100 0000 - E1FF FFFF
0184 8388 MAR226 Controls DDR2 CE0 Range E200 0000 - E2FF FFFF
0184 838C MAR227 Controls DDR2 CE0 Range E300 0000 - E3FF FFFF
0184 8390 MAR228 Controls DDR2 CE0 Range E400 0000 - E4FF FFFF
0184 8394 MAR229 Controls DDR2 CE0 Range E500 0000 - E5FF FFFF
0184 8398 MAR230 Controls DDR2 CE0 Range E600 0000 - E6FF FFFF
0184 839C MAR231 Controls DDR2 CE0 Range E700 0000 - E7FF FFFF
0184 83A0 MAR232 Controls DDR2 CE0 Range E800 0000 - E8FF FFFF
0184 83A4 MAR233 Controls DDR2 CE0 Range E900 0000 - E9FF FFFF
0184 83A8 MAR234 Controls DDR2 CE0 Range EA00 0000 - EAFF FFFF
0184 83AC MAR235 Controls DDR2 CE0 Range EB00 0000 - EBFF FFFF
0184 83B0 MAR236 Controls DDR2 CE0 Range EC00 0000 - ECFF FFFF
0184 83B4 MAR237 Controls DDR2 CE0 Range ED00 0000 - EDFF FFFF
0184 83B8 MAR238 Controls DDR2 CE0 Range EE00 0000 - EEFF FFFF
0184 83BC MAR239 Controls DDR2 CE0 Range EF00 0000 - EFFF FFFF
MAR240 to
0184 83C0 -0184 83FC Reserved
MAR255
Table 5-9. Megamodule L1/L2 Memory Protection Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
0184 A000 L2MPFAR L2 memory protection fault address register
0184 A004 L2MPFSR L2 memory protection fault status register
0184 A008 L2MPFCR L2 memory protection fault command register
0184 A00C - 0184 A0FF - Reserved
0184 A100 L2MPLK0 L2 memory protection lock key bits [31:0]
0184 A104 L2MPLK1 L2 memory protection lock key bits [63:32]
0184 A108 L2MPLK2 L2 memory protection lock key bits [95:64]
0184 A10C L2MPLK3 L2 memory protection lock key bits [127:96]
0184 A110 L2MPLKCMD L2 memory protection lock key command register
0184 A114 L2MPLKSTAT L2 memory protection lock key status register
0184 A118 - 0184 A1FF - Reserved
0184 A200 L2MPPA0 L2 memory protection page attribute register 0
0184 A204 L2MPPA1 L2 memory protection page attribute register 1
0184 A208 L2MPPA2 L2 memory protection page attribute register 2
Copyright © 2005–2012, Texas Instruments Incorporated C64x+ Megamodule 93
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
