Page #186 background imageLoading...
Page #186 background image
TMS320C6455
SPRS276M MAY 2005REVISED MARCH 2012
www.ti.com
7.13.1 McBSP Device-Specific Information
The CLKS signal is shared by both McBSP0 and McBSP1 on this device. Also, the CLKGDV field of the
Sample Rate Generator Register (SRGR) must always be set to a value of 1 or greater.
The McBSP Data Receive Register (DRR) and Data Transmit Register (DXR) can be accessed through
two separate busses: a configuration bus and a data bus. Both paths can be used by the CPU and the
EDMA. The data bus should be used to service the McBSP as this path provides better performance.
However, since the data path shares a bridge with the PCI and UTOPIA peripherals (see Figure 4-1), the
configuration path should be used in cases where these peripherals are being used to avoid any
performance degradation. Note that the PCI peripheral consists of an independent master and slave.
Performance degradation is only a concern when this peripheral is used to initiate transactions on the
external bus.
7.13.2 McBSP Peripheral Register Descriptions
Table 7-57. McBSP 0 Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME COMMENTS
The CPU and EDMA3
controller can only read
028C 0000 DRR0 McBSP0 Data Receive Register via Configuration Bus
this register; they cannot
write to it.
3000 0000 DRR0 McBSP0 Data Receive Register via EDMA3 Bus
028C 0004 DXR0 McBSP0 Data Transmit Register via Configuration Bus
3000 0010 DXR0 McBSP0 Data Transmit Register via EDMA Bus
028C 0008 SPCR0 McBSP0 Serial Port Control Register
028C 000C RCR0 McBSP0 Receive Control Register
028C 0010 XCR0 McBSP0 Transmit Control Register
028C 0014 SRGR0 McBSP0 Sample Rate Generator register
028C 0018 MCR0 McBSP0 Multichannel Control Register
McBSP0 Enhanced Receive Channel Enable
028C 001C RCERE00
Register 0 Partition A/B
McBSP0 Enhanced Transmit Channel Enable
028C 0020 XCERE00
Register 0 Partition A/B
028C 0024 PCR0 McBSP0 Pin Control Register
McBSP0 Enhanced Receive Channel Enable
028C 0028 RCERE10
Register 1 Partition C/D
McBSP0 Enhanced Transmit Channel Enable
028C 002C XCERE10
Register 1 Partition C/D
McBSP0 Enhanced Receive Channel Enable
028C 0030 RCERE20
Register 2 Partition E/F
McBSP0 Enhanced Transmit Channel Enable
028C 0034 XCERE20
Register 2 Partition E/F
McBSP0 Enhanced Receive Channel Enable
028C 0038 RCERE30
Register 3 Partition G/H
McBSP0 Enhanced Transmit Channel Enable
028C 003C XCERE30
Register 3 Partition G/H
028C 0040 - 028F FFFF - Reserved
186 C64x+ Peripheral Information and Electrical Specifications Copyright © 2005–2012, Texas Instruments Incorporated
