SPRS276M –MAY 2005–REVISED MARCH 2012 www.ti.com
7.8.3.1 PLL Controller Divider 1 Register
The PLL controller divider 1 register (PLLDIV1) is shown in Figure 7-24 and described in Table 7-33.
31 16
Reserved
R-0
15 14 5 4 0
D1EN Reserved RATIO
R/W-1 R-0 R/W-1
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Figure 7-24. PLL Controller Divider 1 Register (PLLDIV1) [Hex Address: 029C 0118]
Table 7-33. PLL Controller Divider 1 Register (PLLDIV1) Field Descriptions
Bit Field Value Description
31:16 Reserved 0 Reserved. The reserved bit location is always read as 0. A value written to this field has no effect.
15 D1EN Divider D1 enable bit.
0 Divider D1 is disabled. No clock output.
1 Divider D1 is enabled.
14:5 Reserved 0 Reserved. The reserved bit location is always read as 0. A value written to this field has no effect.
4:0 RATIO 0-1Fh Divider ratio bits.
1h ÷2. Divide frequency by 2.
4h ÷5. Divide frequency by 5.
Others Reserved
150 C64x+ Peripheral Information and Electrical Specifications Copyright © 2005–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455

Texas Instruments TMS320C6455 Specifications

General

Clock Speed	1.0 GHz
Core Count	1
On-Chip RAM	Yes
Data Width	32-bit
Data Bus Width	64-bit
Operating Voltage	1.2 V
I/O Voltage	3.3 V
Instruction Set	TMS320C64x+
Memory	DDR2
Package Type	BGA
External Memory Interface	EMIF
Interfaces	I2C, SPI
