TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012
www.ti.com
Table 7-112. RapidIO Control Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02D0 05A0 RIO_QUEUE8_TXDMA_CP Queue Transmit DMA Completion Pointer Register 8
02D0 05A4 RIO_QUEUE9_TXDMA_CP Queue Transmit DMA Completion Pointer Register 9
02D0 05A8 RIO_QUEUE10_TXDMA_CP Queue Transmit DMA Completion Pointer Register 10
02D0 05AC RIO_QUEUE11_TXDMA_CP Queue Transmit DMA Completion Pointer Register 11
02D0 05B0 RIO_QUEUE12_TXDMA_CP Queue Transmit DMA Completion Pointer Register 12
02D0 05B4 RIO_QUEUE13_TXDMA_CP Queue Transmit DMA Completion Pointer Register 13
02D0 05B8 RIO_QUEUE14_TXDMA_CP Queue Transmit DMA Completion Pointer Register 14
02D0 05BC RIO_QUEUE15_TXDMA_CP Queue Transmit DMA Completion Pointer Register 15
02D0 05D0 - 02D0 05FC - Reserved
02D0 0600 RIO_QUEUE0_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 0
02D0 0604 RIO_QUEUE1_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 1
02D0 0608 RIO_QUEUE2_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 2
02D0 060C RIO_QUEUE3_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 3
02D0 0610 RIO_QUEUE4_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 4
02D0 0614 RIO_QUEUE5_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 5
02D0 0618 RIO_QUEUE6_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 6
02D0 061C RIO_QUEUE7_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 7
02D0 0620 RIO_QUEUE8_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 8
02D0 0624 RIO_QUEUE9_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 9
02D0 0628 RIO_QUEUE10_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 10
02D0 062C RIO_QUEUE11_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 11
02D0 0630 RIO_QUEUE12_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 12
02D0 0634 RIO_QUEUE13_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 13
02D0 0638 RIO_QUEUE14_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 14
02D0 063C RIO_QUEUE15_RXDMA_HDP Queue Receive DMA Head Descriptor Pointer Register 15
02D0 0640 - 02D0 067C - Reserved
02D0 0680 RIO_QUEUE0_RXDMA_CP Queue Receive DMA Completion Pointer Register 0
02D0 0684 RIO_QUEUE1_RXDMA_CP Queue Receive DMA Completion Pointer Register 1
02D0 0688 RIO_QUEUE2_RXDMA_CP Queue Receive DMA Completion Pointer Register 2
02D0 068C RIO_QUEUE3_RXDMA_CP Queue Receive DMA Completion Pointer Register 3
02D0 0690 RIO_QUEUE4_RXDMA_CP Queue Receive DMA Completion Pointer Register 4
02D0 0694 RIO_QUEUE5_RXDMA_CP Queue Receive DMA Completion Pointer Register 5
02D0 0698 RIO_QUEUE6_RXDMA_CP Queue Receive DMA Completion Pointer Register 6
02D0 069C RIO_QUEUE7_RXDMA_CP Queue Receive DMA Completion Pointer Register 7
02D0 06A0 RIO_QUEUE8_RXDMA_CP Queue Receive DMA Completion Pointer Register 8
02D0 06A4 RIO_QUEUE9_RXDMA_CP Queue Receive DMA Completion Pointer Register 9
02D0 06A8 RIO_QUEUE10_RXDMA_CP Queue Receive DMA Completion Pointer Register 10
02D0 06AC RIO_QUEUE11_RXDMA_CP Queue Receive DMA Completion Pointer Register 11
02D0 06B0 RIO_QUEUE12_RXDMA_CP Queue Receive DMA Completion Pointer Register 12
02D0 06B4 RIO_QUEUE13_RXDMA_CP Queue Receive DMA Completion Pointer Register 13
02D0 06B8 RIO_QUEUE14_RXDMA_CP Queue Receive DMA Completion Pointer Register 14
02D0 06BC RIO_QUEUE15_RXDMA_CP Queue Receive DMA Completion Pointer Register 15
02D0 06C0 - 02D0 006FC - Reserved
02D0 0700 RIO_TX_QUEUE_TEAR_DOWN Transmit Queue Teardown Register
02D0 0704 RIO_TX_CPPI_FLOW_MASKS0 Transmit CPPI Supported Flow Mask Register 0
02D0 0708 RIO_TX_CPPI_FLOW_MASKS1 Transmit CPPI Supported Flow Mask Register 1
02D0 070C RIO_TX_CPPI_FLOW_MASKS2 Transmit CPPI Supported Flow Mask Register 2
238 C64x+ Peripheral Information and Electrical Specifications Copyright © 2005–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
