TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012 www.ti.com
Table 7-112. RapidIO Control Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02D0 11A8 RIO_SP3_ACKID_STAT Port 3 Local Acknowledge ID Status CSR
02D0 11AC - 02D0 11B4 - Reserved
02D0 11B8 RIO_SP3_ERR_STAT Port 3 Error and Status CSR
02D0 11BC RIO_SP3_CTL Port 3 Control CSR
02D0 11C0 - 02D0 1FFC - Reserved
RapidIO Extended Feature - Error Management Registers
02D0 2000 RIO_ERR_RPT_BH Error Reporting Block Header
02D0 2004 - Reserved
02D0 2008 RIO_ERR_DET Logical/Transport Layer Error Detect CSR
02D0 200C RIO_ERR_EN Logical/Transport Layer Error Enable CSR
02D0 2010 RIO_H_ADDR_CAPT Logical/Transport Layer High Address Capture CSR
02D0 2014 RIO_ADDR_CAPT Logical/Transport Layer Address Capture CSR
02D0 2018 RIO_ID_CAPT Logical/Transport Layer Device ID Capture CSR
02D0 201C RIO_CTRL_CAPT Logical/Transport Layer Control Capture CSR
02D0 2020 - 02D0 2024 - Reserved
02D0 2028 RIO_PW_TGT_ID Port-Write Target Device ID CSR
02D0 202C - 02D0 203C - Reserved
02D0 2040 RIO_SP0_ERR_DET Port 0 Error Detect CSR
02D0 2044 RIO_SP0_RATE_EN Port 0 Error Enable CSR
02D0 2048 RIO_SP0_ERR_ATTR_CAPT_DBG0 Port 0 Attributes Error Capture CSR 0
02D0 204C RIO_SP0_ERR_CAPT_DBG1 Port 0 Packet/Control Symbol Error Capture CSR 1
02D0 2050 RIO_SP0_ERR_CAPT_DBG2 Port 0 Packet/Control Symbol Error Capture CSR 2
02D0 2054 RIO_SP0_ERR_CAPT_DBG3 Port 0 Packet/Control Symbol Error Capture CSR 3
02D0 2058 RIO_SP0_ERR_CAPT_DBG4 Port 0 Packet/Control Symbol Error Capture CSR 4
02D0 205C - 02D0 2064 - Reserved
02D0 2068 RIO_SP0_ERR_RATE Port 0 Error Rate CSR 0
02D0 206C RIO_SP0_ERR_THRESH Port 0 Error Rate Threshold CSR
02D0 2070 - 02D0 207C - Reserved
02D0 2080 RIO_SP1_ERR_DET Port 1 Error Detect CSR
02D0 2084 RIO_SP1_RATE_EN Port 1 Error Enable CSR
02D0 2088 RIO_SP1_ERR_ATTR_CAPT_DBG0 Port 1 Attributes Error Capture CSR 0
02D0 208C RIO_SP1_ERR_CAPT_DBG1 Port 1 Packet/Control Symbol Error Capture CSR 1
02D0 2090 RIO_SP1_ERR_CAPT_DBG2 Port 1 Packet/Control Symbol Error Capture CSR 2
02D0 2094 RIO_SP1_ERR_CAPT_DBG3 Port 1 Packet/Control Symbol Error Capture CSR 3
02D0 2098 RIO_SP1_ERR_CAPT_DBG4 Port 1 Packet/Control Symbol Error Capture CSR 4
02D0 209C - 02D0 20A4 - Reserved
02D0 20A8 RIO_SP1_ERR_RATE Port 1 Error Rate CSR
02D0 20AC RIO_SP1_ERR_THRESH Port 1 Error Rate Threshold CSR
02D0 20B0 - 02D0 20BC - Reserved
02D0 20C0 RIO_SP2_ERR_DET Port 2 Error Detect CSR
02D0 20C4 RIO_SP2_RATE_EN Port 2 Error Enable CSR
02D0 20C8 RIO_SP2_ERR_ATTR_CAPT_DBG0 Port 2 Attributes Error Capture CSR 0
02D0 20CC RIO_SP2_ERR_CAPT_DBG1 Port 2 Packet/Control Symbol Error Capture CSR 1
02D0 20D0 RIO_SP2_ERR_CAPT_DBG2 Port 2 Packet/Control Symbol Error Capture CSR 2
02D0 20D4 RIO_SP2_ERR_CAPT_DBG3 Port 2 Packet/Control Symbol Error Capture CSR 3
02D0 20D8 RIO_SP2_ERR_CAPT_DBG4 Port 2 Packet/Control Symbol Error Capture CSR 4
02D0 20DC - 02D0 20E4 - Reserved
242 C64x+ Peripheral Information and Electrical Specifications Copyright © 2005–2012, Texas Instruments Incorporated
