TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012 www.ti.com
7.18.3 PCI Electrical Data/Timing
Texas Instruments (TI) has performed the simulation and system characterization to ensure that the PCI
peripheral meets all AC timing specifications as required by the PCI Local Bus Specification (version 2.3).
The AC timing specifications are not reproduced here. For more information on the AC timing
specifications, see section 4.2.3, Timing Specification (33 MHz timing), and section 7.6.4, Timing
Specification (66 MHz timing), of the PCI Local Bus Specification (version 2.3). Note that the C6455 PCI
peripheral only supports 3.3-V signaling.
228 C64x+ Peripheral Information and Electrical Specifications Copyright © 2005–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
