UXCLK
1
2
3
4
4
URCLK
1
2
3
4
4
TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012 www.ti.com
7.19.3 UTOPIA Electrical Data/Timing
Table 7-106. Timing Requirements for UXCLK
(1)
(see Figure 7-74)
-720
-850
A-1000/-1000
NO. UNIT
-1200
MIN MAX
1 t
c(UXCK)
Cycle time, UXCLK 20 ns
2 t
w(UXCKH)
Pulse duration, UXCLK high 0.4t
c(UXCK)
0.6t
c(UXCK)
ns
3 t
w(UXCKL)
Pulse duration, UXCLK low 0.4t
c(UXCK)
0.6t
c(UXCK)
ns
4 t
t(UXCK)
Transition time, UXCLK 2 ns
(1) The reference points for the rise and fall transitions are measured at V
IL
MAX and V
IH
MIN.
Figure 7-74. UXCLK Timing
Table 7-107. Timing Requirements for URCLK
(1)
(see Figure 7-75)
-720
-850
A-1000/-1000
NO. UNIT
-1200
MIN MAX
1 t
c(URCK)
Cycle time, URCLK 20 ns
2 t
w(URCKH)
Pulse duration, URCLK high 0.4t
c(URCK)
0.6t
c(URCK)
ns
3 t
w(URCKL)
Pulse duration, URCLK low 0.4t
c(URCK)
0.6t
c(URCK)
ns
4 t
t(URCK)
Transition time, URCLK 2 ns
(1) The reference points for the rise and fall transitions are measured at V
IL
MAX and V
IH
MIN.
Figure 7-75. URCLK Timing
