TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012
www.ti.com
5.6 Megamodule Revision
The version and revision of the C64x+ Megamodule can be read from the Megamodule Revision ID
Register (MM_REVID) located at address 0181 2000h. The MM_REVID register is shown in Figure 5-5
and described in Table 5-3. The C64x+ Megamodule revision is dependant on the silicon revision being
used. For more information, see the TMS320C6455/54 Digital Signal Processor Silicon Errata (literature
number SPRZ234) .
31 16 15 0
VERSION REVISION
(A)
R-1h R-n
LEGEND: R = Read only; -n = value after reset
A. The C64x+ Megamodule revision is dependant on the silicon revision being used. For more information, see
the TMS320C6455/54 Digital Signal Processor Silicon Errata (literature number SPRZ234) .
Figure 5-5. Megamodule Revision ID Register (MM_REVID) [Hex Address: 0181 2000h]
Table 5-3. Megamodule Revision ID Register (MM_REVID) Field Descriptions
Bit Field Value Description
31:16 VERSION 1h Version of the C64x+ Megamodule implemented on the device. This field is always read as 1h.
15:0 REVISION Revision of the C64x+ Megamodule version implemented on the device. The C64x+ Megamodule
revision is dependant on the silicon revision being used. For more information, see the
TMS320C6455/54 Digital Signal Processor Silicon Errata (literature number SPRZ234) .
88 C64x+ Megamodule Copyright © 2005–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
