7.7.3.8 PLL Controller Clock Align Control Register
The PLL controller clock align control register (ALNCTL) is shown in Figure 7-18 and described in Table 7-
26.
31 16
Reserved
R-0
15 5 4 3 2 0
Reserved ALN5 ALN4 Reserved
R-0 R-1 R-1 R-1
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Figure 7-18. PLL Controller Clock Align Control Register (ALNCTL) [Hex Address: 029A 0140]
Table 7-26. PLL Controller Clock Align Control Register (ALNCTL) Field Descriptions
Bit Field Value Description
31:5 Reserved 0 Reserved. The reserved bit location is always read as 0. A value written to this field has no effect.
4:3 ALNn SYSCLKn alignment. Do not change the default values of these fields.
0 Do not align SYSCLKn to other SYSCLKs during GO operation. If SYSn in DCHANGE is set to 1,
SYSCLKn switches to the new ratio immediately after the GOSET bit in PLLCMD is set.
1 Align SYSCLKn to other SYSCLKs selected in ALNCTL when the GOSET bit in PLLCMD is set.
The SYSCLKn ratio is set to the ratio programmed in the RATIO bit in PLLDIVn.
2:0 Reserved 0 Reserved. The reserved bit location is always read as 0. A value written to this field has no effect.
Copyright © 2005–2012, Texas Instruments Incorporated C64x+ Peripheral Information and Electrical Specifications 143
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
