7.17.2 TCP2 Peripheral Register Descriptions
Table 7-97. TCP2 Registers
EDMA BUS CONFIGURATION BUS
ACRONYM REGISTER NAME
HEX ADDRESS RANGE HEX ADDRESS RANGE
5000 0000 - TCPIC0 TCP2 Input Configuration Register 0
5000 0004 - TCPIC1 TCP2 Input Configuration Register 1
5000 0008 - TCPIC2 TCP2 Input Configuration Register 2
5000 000C - TCPIC3 TCP2 Input Configuration Register 3
5000 0010 - TCPIC4 TCP2 Input Configuration Register 4
5000 0014 - TCPIC5 TCP2 Input Configuration Register 5
5000 0018 - TCPIC6 TCP2 Input Configuration Register 6
5000 001C - TCPIC7 TCP2 Input Configuration Register 7
5000 0020 - TCPIC8 TCP2 Input Configuration Register 8
5000 0024 - TCPIC9 TCP2 Input Configuration Register 9
5000 0028 - TCPIC10 TCP2 Input Configuration Register 10
5000 002C - TCPIC11 TCP2 Input Configuration Register 11
5000 0030 - TCPIC12 TCP2 Input Configuration Register 12
5000 0034 - TCPIC13 TCP2 Input Configuration Register 13
5000 0038 - TCPIC14 TCP2 Input Configuration Register 14
5000 003C - TCPIC15 TCP2 Input Configuration Register 15
5000 0040 - TCPOUT0 TCP2 Output Parameters Register 0
5000 0044 - TCPOUT1 TCP2 Output Parameters Register 1
5000 0048 - TCPOUTP2 TCP2 Output Parameters Register 2
5001 0000 N/A X0 TCP2 Data/Sys and Parity Memory
5003 0000 N/A W0 TCP2 Extrinsic Mem 0
5004 0000 N/A W1 TCP2 Extrinsic Mem 1
5005 0000 N/A I0 TCP2 Interleaver Memory
5006 0000 N/A O0 TCP2 Output/Decision Memory
5007 0000 N/A S0 TCP2 Scratch Pad Memory
5008 0000 N/A T0 TCP2 Beta State Memory
5009 0000 N/A C0 TCP2 CRC Memory
500A 0000 N/A B0 TCP2 Beta Prolog Memory
500B 0000 N/A A0 TCP2 Alpha Prolog Memory
02BA 0000 TCPPID TCP2 Peripheral Identification Register
N/A 02BA 004C TCPEXE TCP2 Execute Register
N/A 02BA 0050 TCPEND TCP2 Endianness Register
N/A 02BA 0060 TCPERR TCP2 Error Register
N/A 02BA 0068 TCPSTAT TCP2 Status Register
N/A 02BA 0070 TCPEMU TCP2 Emulation Register
N/A 02BA 005C - 02BB FFFF - Reserved
