TMS320C6455
www.ti.com SPRS276M –MAY 2005–REVISED MARCH 2012
7.18.2 PCI Peripheral Register Descriptions
Table 7-99. PCI Configuration Registers
PCI HOST ACCESS
ACRONYM PCI HOST ACCESS REGISTER NAME
HEX ADDRESS OFFSET
0x00 PCIVENDEV Vendor ID/Device ID
0x04 PCICSR Command/Status
0x08 PCICLREV Class Code/Revision ID
0x0C PCICLINE BIST/Header Type/Latency Timer/Cacheline Size
0x10 PCIBAR0 Base Address 0
0x14 PCIBAR1 Base Address 1
0x18 PCIBAR2 Base Address 2
0x1C PCIBAR3 Base Address 3
0x20 PCIBAR4 Base Address 4
0x24 PCIBAR5 Base Address 5
0x28 - 0x2B - Reserved
0x2C PCISUBID Subsystem Vendor ID/Subsystem ID
0x30 - Reserved
0x34 PCICPBPTR Capabilities Pointer
0x38 - 0x3B - Reserved
0x3C PCILGINT Max Latency/Min Grant/Interrupt Pin/Interrupt Line
0x40 - 0x7F - Reserved
Table 7-100. PCI Back-End Configuration Registers
DSP ACCESS
ACRONYM DSP ACCESS REGISTER NAME
HEX ADDRESS RANGE
02C0 0000 - 02C0 000F - Reserved
02C0 0010 PCISTATSET PCI Status Set Register
02C0 0014 PCISTATCLR PCI Status Clear Register
02C0 0018 - 02C0 001F - Reserved
02C0 0020 PCIHINTSET PCI Host Interrupt Enable Set Register
02C0 0024 PCIHINTCLR PCI Host Interrupt Enable Clear Register
02C0 0028 - 02C0 002F - Reserved
02C0 0030 PCIBINTSET PCI Back End Application Interrupt Enable Set Register
02C0 0034 PCIBINTCLR PCI Back End Application Interrupt Enable Clear Register
02C0 0038 PCIBCLKMGT PCI Back End Application Clock Management Register
02C0 003C - 02C0 00FF - Reserved
02C0 0100 PCIVENDEVMIR PCI Vendor ID/Device ID Mirror Register
02C0 0104 PCICSRMIR PCI Command/Status Mirror Register
02C0 0108 PCICLREVMIR PCI Class Code/Revision ID Mirror Register
02C0 010C PCICLINEMIR PCI BIST/Header Type/Latency Timer/Cacheline Size Mirror Register
02C0 0110 PCIBAR0MSK PCI Base Address Mask Register 0
02C0 0114 PCIBAR1MSK PCI Base Address Mask Register 1
02C0 0118 PCIBAR2MSK PCI Base Address Mask Register 2
02C0 011C PCIBAR3MSK PCI Base Address Mask Register 3
02C0 0120 PCIBAR4MSK PCI Base Address Mask Register 4
02C0 0124 PCIBAR5MSK PCI Base Address Mask Register 5
02C0 0128 - 02C0 012B - Reserved
02C0 012C PCISUBIDMIR PCI Subsystem Vendor ID/Subsystem ID Mirror Register
02C0 0130 - Reserved
