TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012
www.ti.com
7.20.2 Serial RapidIO Peripheral Register Descriptions
Table 7-112. RapidIO Control Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02D0 0000 RIO_PID Peripheral Identification Register
02D0 0004 RIO_PCR Peripheral Control Register
02D0 0008 - 02D0 001C - Reserved
02D0 0020 RIO_PER_SET_CNTL Peripheral Settings Control Register
02D0 0024 - 02D0 002C - Reserved
02D0 0030 RIO_GBL_EN Peripheral Global Enable Register
02D0 0034 RIO_GBL_EN_STAT Peripheral Global Enable Status
02D0 0038 RIO_BLK0_EN Block Enable 0
02D0 003C RIO_BLK0_EN_STAT Block Enable Status 0
02D0 0040 RIO_BLK1_EN Block Enable 1
02D0 0044 RIO_BLK1_EN_STAT Block Enable Status 1
02D0 0048 RIO_BLK2_EN Block Enable 2
02D0 004C RIO_BLK2_EN_STAT Block Enable Status 2
02D0 0050 RIO_BLK3_EN Block Enable 3
02D0 0054 RIO_BLK3_EN_STAT Block Enable Status 3
02D0 0058 RIO_BLK4_EN Block Enable 4
02D0 005C RIO_BLK4_EN_STAT Block Enable Status 4
02D0 0060 RIO_BLK5_EN Block Enable 5
02D0 0064 RIO_BLK5_EN_STAT Block Enable Status 5
02D0 0068 RIO_BLK6_EN Block Enable 6
02D0 006C RIO_BLK6_EN_STAT Block Enable Status 6
02D0 0070 RIO_BLK7_EN Block Enable 7
02D0 0074 RIO_BLK7_EN_STAT Block Enable Status 7
02D0 0078 RIO_BLK8_EN Block Enable 8
02D0 007C RIO_BLK8_EN_STAT Block Enable Status 8
02D0 0080 RIO_DEVICEID_REG1 RapidIO DEVICEID1 Register
02D0 0084 RIO_DEVICEID_REG2 RapidIO DEVICEID2 Register
02D0 0088 - 02D0 008C - Reserved
02D0 0090 RIO_PF_16B_CNTL0 Packet Forwarding Register 0 for 16-bit Device IDs
02D0 0094 RIO_PF_8B_CNTL0 Packet Forwarding Register 0 for 8-bit Device IDs
02D0 0098 RIO_PF_16B_CNTL1 Packet Forwarding Register 1 for 16-bit Device IDs
02D0 009C RIO_PF_8B_CNTL1 Packet Forwarding Register 1 for 8-bit Device IDs
02D0 00A0 RIO_PF_16B_CNTL2 Packet Forwarding Register 2 for 16-bit Device IDs
02D0 00A4 RIO_PF_8B_CNTL2 Packet Forwarding Register 2 for 8-bit Device IDs
02D0 00A8 RIO_PF_16B_CNTL3 Packet Forwarding Register 3 for 16-bit Device IDs
02D0 00AC RIO_PF_8B_CNTL3 Packet Forwarding Register 3 for 8-bit Device IDs
02D0 00B0 - 02D0 00FC - Reserved
02D0 0100 RIO_SERDES_CFGRX0_CNTL SERDES Receive Channel Configuration Register 0
02D0 0104 RIO_SERDES_CFGRX1_CNTL SERDES Receive Channel Configuration Register 1
02D0 0108 RIO_SERDES_CFGRX2_CNTL SERDES Receive Channel Configuration Register 2
02D0 010C RIO_SERDES_CFGRX3_CNTL SERDES Receive Channel Configuration Register 3
02D0 0110 RIO_SERDES_CFGTX0_CNTL SERDES Transmit Channel Configuration Register 0
02D0 0114 RIO_SERDES_CFGTX1_CNTL SERDES Transmit Channel Configuration Register 1
02D0 0118 RIO_SERDES_CFGTX2_CNTL SERDES Transmit Channel Configuration Register 2
02D0 011C RIO_SERDES_CFGTX3_CNTL SERDES Transmit Channel Configuration Register 3
234 C64x+ Peripheral Information and Electrical Specifications Copyright © 2005–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
