TMS320C6455
www.ti.com SPRS276M –MAY 2005–REVISED MARCH 2012
7.15 Timers
The timers can be used to: time events, count events, generate pulses, interrupt the CPU, and send
synchronization events to the EDMA3 channel controller.
7.15.1 Timers Device-Specific Information
The C6455 device has two general-purpose timers, Timer0 and Timer1, each of which can be configured
as a general-purpose timer or a watchdog timer. When configured as a general-purpose timer, each timer
can be programmed as a 64-bit timer or as two separate 32-bit timers.
Each timer is made up of two 32-bit counters: a high counter and a low counter. The timer pins, TINPLx
and TOUTLx are connected to the low counter. The high counter does not have any external device pins.
7.15.2 Timers Peripheral Register Descriptions
Table 7-92. Timer 0 Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME COMMENTS
0294 0000 - Reserved
Timer 0 Emulation Management/Clock Speed
0294 0004 EMUMGT_CLKSPD0
Register
0294 0008 - Reserved
0294 000C - Reserved
0294 0010 CNTLO0 Timer 0 Counter Register Low
0294 0014 CNTHI0 Timer 0 Counter Register High
0294 0018 PRDLO0 Timer 0 Period Register Low
0294 001C PRDHI0 Timer 0 Period Register High
0294 0020 TCR0 Timer 0 Control Register
0294 0024 TGCR0 Timer 0 Global Control Register
0294 0028 WDTCR0 Timer 0 Watchdog Timer Control Register
0294 002C - Reserved
0294 0030 - Reserved
0294 0034 - 0297 FFFF - Reserved
Table 7-93. Timer 1 Registers
HEX ADDRESS RANGE ACRONYM REGISTER NAME COMMENTS
0298 0000 - Reserved
0298 0004 EMUMGT_CLKSPD1 Timer 1 Emulation Management/Clock Speed Register
0298 0008 - Reserved
0298 000C - Reserved
0298 0010 CNTLO1 Timer 1 Counter Register Low
0298 0014 CNTHI1 Timer 1 Counter Register High
0298 0018 PRDLO1 Timer 1 Period Register Low
0298 001C PRDHI1 Timer 1 Period Register High
0298 0020 TCR1 Timer 1 Control Register
0298 0024 TGCR1 Timer 1 Global Control Register
0298 0028 WDTCR1 Timer 1 Watchdog Timer Control Register
0298 002C - Reserved
0298 0030 - Reserved
0298 0034 - 0299 FFFF - Reserved
Copyright © 2005–2012, Texas Instruments Incorporated C64x+ Peripheral Information and Electrical Specifications 217
