TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012
www.ti.com
Table 7-4. EDMA3 Channel Controller Registers (continued)
HEX ADDRESS RANGE ACRONYM REGISTER NAME
02A0 0368 DRAE5 DMA Region Access Enable Register for Region 5
02A0 036C DRAEH5 DMA Region Access Enable Register High for Region 5
02A0 0370 DRAE6 DMA Region Access Enable Register for Region 6
02A0 0374 DRAEH6 DMA Region Access Enable Register High for Region 6
02A0 0378 DRAE7 DMA Region Access Enable Register for Region 7
02A0 037C DRAEH7 DMA Region Access Enable Register High for Region 7
02A0 0380 QRAE0 QDMA Region Access Enable Register for Region 0
02A0 0384 QRAE1 QDMA Region Access Enable Register for Region 1
02A0 0388 QRAE2 QDMA Region Access Enable Register for Region 2
02A0 038C QRAE3 QDMA Region Access Enable Register for Region 3
02A0 0390 - 02A0 039C - Reserved
02A0 0400 Q0E0 Event Queue 0 Entry Register 0
02A0 0404 Q0E1 Event Queue 0 Entry Register 1
02A0 0408 Q0E2 Event Queue 0 Entry Register 2
02A0 040C Q0E3 Event Queue 0 Entry Register 3
02A0 0410 Q0E4 Event Queue 0 Entry Register 4
02A0 0414 Q0E5 Event Queue 0 Entry Register 5
02A0 0418 Q0E6 Event Queue 0 Entry Register 6
02A0 041C Q0E7 Event Queue 0 Entry Register 7
02A0 0420 Q0E8 Event Queue 0 Entry Register 8
02A0 0424 Q0E9 Event Queue 0 Entry Register 9
02A0 0428 Q0E10 Event Queue 0 Entry Register 10
02A0 042C Q0E11 Event Queue 0 Entry Register 11
02A0 0430 Q0E12 Event Queue 0 Entry Register 12
02A0 0434 Q0E13 Event Queue 0 Entry Register 13
02A0 0438 Q0E14 Event Queue 0 Entry Register 14
02A0 043C Q0E15 Event Queue 0 Entry Register 15
02A0 0440 Q1E0 Event Queue 1 Entry Register 0
02A0 0444 Q1E1 Event Queue 1 Entry Register 1
02A0 0448 Q1E2 Event Queue 1 Entry Register 2
02A0 044C Q1E3 Event Queue 1 Entry Register 3
02A0 0450 Q1E4 Event Queue 1 Entry Register 4
02A0 0454 Q1E5 Event Queue 1 Entry Register 5
02A0 0458 Q1E6 Event Queue 1 Entry Register 6
02A0 045C Q1E7 Event Queue 1 Entry Register 7
02A0 0460 Q1E8 Event Queue 1 Entry Register 8
02A0 0464 Q1E9 Event Queue 1 Entry Register 9
02A0 0468 Q1E10 Event Queue 1 Entry Register 10
02A0 046C Q1E11 Event Queue 1 Entry Register 11
02A0 0470 Q1E12 Event Queue 1 Entry Register 12
02A0 0474 Q1E13 Event Queue 1 Entry Register 13
02A0 0478 Q1E14 Event Queue 1 Entry Register 14
02A0 047C Q1E15 Event Queue 1 Entry Register 15
02A0 0480 Q2E0 Event Queue 2 Entry Register 0
02A0 0484 Q2E1 Event Queue 2 Entry Register 1
02A0 0488 Q2E2 Event Queue 2 Entry Register 2
02A0 048C Q2E3 Event Queue 2 Entry Register 3
