TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012
www.ti.com
Table 7-100. PCI Back-End Configuration Registers (continued)
DSP ACCESS
ACRONYM DSP ACCESS REGISTER NAME
HEX ADDRESS RANGE
02C0 0134 PCICPBPTRMIR PCI Capabilities Pointer Mirror Register
02C0 0138 - 02C0 013B - Reserved
02C0 013C PCILGINTMIR PCI Max Latency/Min Grant/Interrupt Pin/Interrupt Line Mirror Register
02C0 0140 - 02C0 017F - Reserved
02C0 0180 PCISLVCNTL PCI Slave Control Register
02C0 0184 - 02C0 01BF - Reserved
02C0 01C0 PCIBAR0TRL PCI Slave Base Address 0 Translation Register
02C0 01C4 PCIBAR1TRL PCI Slave Base Address 1 Translation Register
02C0 01C8 PCIBAR2TRL PCI Slave Base Address 2 Translation Register
02C0 01CC PCIBAR3TRL PCI Slave Base Address 3 Translation Register
02C0 01D0 PCIBAR4TRL PCI Slave Base Address 4 Translation Register
02C0 01D4 PCIBAR5TRL PCI Slave Base Address 5 Translation Register
02C0 01D8 - 02C0 01DF - Reserved
02C0 01E0 PCIBAR0MIR PCI Base Address Register 0 Mirror Register
02C0 01E4 PCIBAR1MIR PCI Base Address Register 1 Mirror Register
02C0 01E8 PCIBAR2MIR PCI Base Address Register 2 Mirror Register
02C0 01EC PCIBAR3MIR PCI Base Address Register 3 Mirror Register
02C0 01F0 PCIBAR4MIR PCI Base Address Register 4 Mirror Register
02C0 01F4 PCIBAR5MIR PCI Base Address Register 5 Mirror Register
02C0 01F8 - 02C0 02FF - Reserved
02C0 0300 PCIMCFGDAT PCI Master Configuration/IO Access Data Register
02C0 0304 PCIMCFGADR PCI Master Configuration/IO Access Address Register
02C0 0308 PCIMCFGCMD PCI Master Configuration/IO Access Command Register
02C0 030C - 02C0 030F - Reserved
02C0 0310 PCIMSTCFG PCI Master Configuration Register
Table 7-101. DSP-to-PCI Address Translation Registers
DSP ACCESS
ACRONYM DSP ACCESS REGISTER NAME
HEX ADDRESS RANGE
02C0 0314 PCIADDSUB0 PCI Address Substitute 0 Register
02C0 0318 PCIADDSUB1 PCI Address Substitute 1 Register
02C0 031C PCIADDSUB2 PCI Address Substitute 2 Register
02C0 0320 PCIADDSUB3 PCI Address Substitute 3 Register
02C0 0324 PCIADDSUB4 PCI Address Substitute 4 Register
02C0 0328 PCIADDSUB5 PCI Address Substitute 5 Register
02C0 032C PCIADDSUB6 PCI Address Substitute 6 Register
02C0 0330 PCIADDSUB7 PCI Address Substitute 7 Register
02C0 0334 PCIADDSUB8 PCI Address Substitute 8 Register
02C0 0338 PCIADDSUB9 PCI Address Substitute 9 Register
02C0 033C PCIADDSUB10 PCI Address Substitute 10 Register
02C0 0340 PCIADDSUB11 PCI Address Substitute 11 Register
02C0 0344 PCIADDSUB12 PCI Address Substitute 12 Register
02C0 0348 PCIADDSUB13 PCI Address Substitute 13 Register
02C0 034C PCIADDSUB14 PCI Address Substitute 14 Register
02C0 0350 PCIADDSUB15 PCI Address Substitute 15 Register
02C0 0354 PCIADDSUB16 PCI Address Substitute 16 Register
02C0 0358 PCIADDSUB17 PCI Address Substitute 17 Register
224 C64x+ Peripheral Information and Electrical Specifications Copyright © 2005–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C6455
