TMS320C6455
SPRS276M –MAY 2005–REVISED MARCH 2012 www.ti.com
Table 2-2. C6455 Memory Map Summary (continued)
MEMORY BLOCK DESCRIPTION BLOCK SIZE (BYTES) HEX ADDRESS RANGE
EMAC Descriptor Memory 8K 02C8 2000 - 02C8 3FFF
Reserved 496K 02C8 4000 - 02CF FFFF
RapidIO Control Registers 256K 02D0 0000 - 02D3 FFFF
Reserved 768K 02D4 0000 - 02DF FFFF
RapidIO CPPI RAM 16K 02E0 0000 - 02E0 3FFF
Reserved 2M - 16K 02E0 4000 - 02FF FFFF
Reserved 16M 0300 0000 - 03FF FFFF
Reserved 192M 0400 0000 - 0FFF FFFF
Reserved 256M 1000 0000 - 1FFF FFFF
Reserved 256M 2000 0000 - 2FFF FFFF
McBSP 0 Data 256 3000 0000 - 3000 00FF
Reserved 64M - 256 3000 0100 - 33FF FFFF
McBSP 1 Data 256 3400 0000 - 3400 00FF
Reserved 64M - 256 3400 0100 - 37FF FFFF
Reserved 64M 3800 0000 - 3BFF FFFF
UTOPIA Receive (Rx) Data Queue 1K 3C00 0000 - 3C00 03FF
UTOPIA Transmit (Tx) Data Queue 1K 3C00 0400 - 3C00 07FF
Reserved 16M - 2K 3C00 0800 - 3CFF FFFF
Reserved 48M 3D00 0000 - 3FFF FFFF
PCI External Memory Space 256M 4000 0000 - 4FFF FFFF
TCP2 Data Registers 128M 5000 0000 - 57FF FFFF
VCP2 Data Registers 128M 5800 0000 - 5FFF FFFF
Reserved 256M 6000 0000 - 6FFF FFFF
EMIFA (EMIF64) Configuration Registers 128M 7000 0000 - 77FF FFFF
DDR2 Memory Controller Configuration Registers 128M 7800 0000 - 7FFF FFFF
Reserved 256M 8000 0000 - 8FFF FFFF
Reserved 256M 9000 0000 - 9FFF FFFF
EMIFA CE2 - SBSRAM/Async
(1)
8M A000 0000 - A07F FFFF
Reserved 256M - 8M A080 0000 - AFFF FFFF
EMIFA CE3 - SBSRAM/Async
(1)
8M B000 0000 - B07F FFFF
Reserved 256M - 8M B080 0000 - BFFF FFFF
EMIFA CE4 - SBSRAM/Async
(1)
8M C000 0000 - C07F FFFF
Reserved 256M - 8M C080 0000 - CFFF FFFF
EMIFA CE5 - SBSRAM/Async
(1)
8M D000 0000 - D07F FFFF
Reserved 256M - 8M D080 0000 - DFFF FFFF
DDR2 Memory Controller CE0 - DDR2 SDRAM 512M E000 0000 - FFFF FFFF
(1) The EMIFA CE0 and CE1 are not functionally supported on the C6455 device and, therefore, are not pinned out.
