Table 2-3. Terminal Functions (continued)
SIGNAL
TYPE
(1)
IPD/IPU
(2)
DESCRIPTION
NAME NO.
AD5
AD7
AD14
AD18
AD22
AD24
AE6
AE8
AE15
AF1
AF16
DV
DD33
AF24 S 3.3-V I/O supply voltage
AG12
AG17
AG23
AH14
AH16
AH24
AJ1
AJ7
AJ15
AJ25
AJ29
L12
L14
L16
L18
M11
M13
M15
M17
M19
N12
1.25-V core supply voltage (-1000 and -1200 devices)
CV
DD
S
1.2-V core supply voltage (-850 and -720 devices)
N14
N16
N18
P13
P15
P17
P19
R12
R14
R16
