USTER HVI SPECTRUM - Error Log; Table 12-1: Description of Diagnostic Function Keys

USTER
®
HVI SPECTRUM Instruction Manual
Uster Technologies, Inc. Chapter 12
Diagnostics • Page 12-5
Button Action
Endurance Test Initiates a continuous Testing Cycle
Positioner Rev Runs transport from back to front
Positioner Fwd Runs transport from front to back
Level 1 Level 1, Level 2, Level 3
Jaw Open Unclamp jaw
Jaw Close Clamp jaw
Breaker Fwd Moves out of home position
Breaker Rev Moves back to home position
New Tare Curve Clamp diagnostics tool (Service Personnel
only)
Frame Grabber Initiates Frame Grabber program
Moisture Test Checks the moisture probe
Pressure Volt Checks the voltage and the pressure
reading
UV Meter Displays voltage and UV values; used to
select the type of mode desired
Scale (grams) Scale readout
Optics (volts) Optics readout
Force (volts) Check for zero force transducer readout
Table 12–1: Description of Diagnostic Function Keys
3 Error Log
The Error Log file located in the
HVI SPECTRUM directory contains many
important system errors, which may be needed for troubleshooting
purposes. A list of error messages and their possible causes are located
in the Appendix of this manual.
