USTER
®
HVI SPECTRUM
Instruction Manual
4.2
HVI SPECTRUM I
• The main control cabinet is 64 cm long and 80 cm deep.
• The Length/Strength cabinet is 84 cm long by 80 cm deep.
• The Length/Strength cabinet is connected to the main control
cabinet by a triangular-shaped support frame that is 70 cm at the
widest part.
• The printer rests on a shelf located to the right of the main control
cabinet that is 50 cm wide and 64 cm deep.
• The
HVI SPECTRUM I
weighs approximately 50 gross kilos (64
net).
Figure 2-2:
HVI SPECTRUM I
Uster Technologies, Inc. Chapter 2
Installation • Page 2-6
