5 Connections
The balance, monitor, keyboard, temperature/relative humidity probe,
and bar code reader should be connected BEFORE the HVI SPECTRUM
is turned ON. Follow the instructions below:
1. Balance - Connect the balance to the cable labeled “COM 2”
located on the back of the computer system.
2. Monitor - Connect the monitor to the connector labeled VGA on
the back of the computer in the control system.
3. Keyboard - The keyboard is attached to the connector labeled
“KB” on the back of the computer. It is equipped with a touch pad
feature for easy use.
Note: Older versions of the HVI SPECTRUM units are equipped with a
keyboard and mouse, which are installed in the same manner.
4. Temperature/Relative Humidity Probe (optional unit) -
The probe cable is attached to a connector on the control board in
the Length/Strength cabinet.
5. Bar Code Reader (optional unit) - Connect the bar code
reader to the cable labeled COM3 located on the 8-Port Rocket
Board panel.
6. Length/Strength - The Length/Strength cabinet connects to the
main Control Cabinet at COM4 located on the 8-Port Rocket board
panel.
