USTER HVI SPECTRUM - Page 59

USTER
®
HVI SPECTRUM Instruction Manual
Uster Technologies, Inc. Chapter 4
Calibration • Page 4-15
IMPORTANT:
The FIRST time the system is calibrated, DEFINED TILE
COLOR: FIXED TILE SEQUENCE MUST be selected! Refer to
figure 4 – 9.
9. Begin calibration by selecting the START button.
10. The “Message” area, located beneath the list of tiles, offers
instructions to the operator.
Note: This message will differ depending on the selection (either
Defined tile color or Auto color detect from the buttons located
beneath the message area). In this example, the Defined tile color has
been chosen.
11. Follow the instructions on the screen by placing each tile on the
color/trash plate as requested.
12. Press the NEXT button to continue.
Note: A check mark will automatically appear in the box beside
each color tile in the “Completed?” area of the screen indicating
the image for that tile has been grabbed.
13. Once the Color head has measured all five tiles, the final results
will be displayed. If any of the readings for the tile are out of
tolerance (FAIL), it will be necessary to perform the calibration
again.
14. When you are finished, select the SAVE CALIBRATION button to
save any modified constants.
15. Select P
RINT RESULTS to send the result to the connected printer.
16. The HALT button is used to stop processing while measurements
are being taken. This option is most commonly used if:
o The wrong tile was placed on the Color head.
o The tile was not centered on the Color head plate.
